Issue 1, 2014

[NH2NH3][M(HCOO)3] (M = Mn2+, Zn2+, Co2+ and Mg2+): structural phase transitions, prominent dielectric anomalies and negative thermal expansion, and magnetic ordering

Abstract

We report here a new class of ammonium metal–formate frameworks of [NH2NH3][M(HCOO)3] (M = Mn2+, Zn2+, Co2+ and Mg2+) incorporating hydrazinium as the cationic template and component. The perovskite Mn and Zn members possess anionic 412·63 metal–formate frameworks with cubic cavities occupied by the NH2NH3+ cations, while the Co and Mg members have chiral 49·66 metal–formate frameworks, with chiral hexagonal channels accommodating NH2NH3+ cations. On heating, the Mn and Zn members undergo phase transitions around 350 K. The structures change from low temperature (LT) polar phases in Pna21 to high temperature (HT) non-polar phases in Pnma, due to the thermally activated librational movement of the NH2 end of the NH2NH3+ in the cavity and significant framework regulation. The Co and Mg members in LT belong to non-polar P212121, are probably antiferroelectric, and they show phase transitions at 380 K (Co) and 348 K (Mg), and the structures change to polar HT phases in P63, triggered by the order–disorder transition of the cation from one unique orientation in LT to three of trigonally-disorder state in HT. Accompanying the phase transitions, which are ferro- to para-electric for Mn and Zn members while antiferro- to ferro-electric for Co and Mg, prominent anisotropic thermal expansions including negative ones, and dielectric anomalies, are observed. The spontaneous polarization values are estimated at 3.58 (Mn, 110 K), 3.48 (Zn, 110 K), 2.61 (Co, 405 K) and 3.44 (Mg, 400 K) μC cm−2, respectively, based on the positive and negative charge separations in the polar structures. The structure–property relevance is established based on the order–disorder transitions of NH2NH3+ and the conformity and adaptability of the metal–formate frameworks to match such order–disorder alternations. The Mn and Co members show spin-canted antiferromagnetic long-range-ordering, with Néel temperatures of 7.9 K and 13.9 K, respectively. Therefore, the two members show coexistence of electric and magnetic orderings in the low temperature region, and they are possible molecule-based multiferroics.

Graphical abstract: [NH2NH3][M(HCOO)3] (M = Mn2+, Zn2+, Co2+ and Mg2+): structural phase transitions, prominent dielectric anomalies and negative thermal expansion, and magnetic ordering

Supplementary files

Article information

Article type
Paper
Submitted
05 sen 2013
Accepted
14 noy 2013
First published
20 dek 2013

Inorg. Chem. Front., 2014,1, 83-98

[NH2NH3][M(HCOO)3] (M = Mn2+, Zn2+, Co2+ and Mg2+): structural phase transitions, prominent dielectric anomalies and negative thermal expansion, and magnetic ordering

S. Chen, R. Shang, K. Hu, Z. Wang and S. Gao, Inorg. Chem. Front., 2014, 1, 83 DOI: 10.1039/C3QI00034F
