Synthesis of single crystal Sn-doped In2O3nanowires: size-dependent conductive characteristics

Abstract

Single crystalline Sn doped In₂O₃ (ITO) NWs (nanowires) were synthesized via an Au-catalyzed VLS (vapor–liquid–solid) method at 600 °C. The different sizes (∼20, ∼40, ∼80 nm) of the Au NPs (nanoparticles) provided the controllable diameters for ITO NWs during growth. Phase and microstructures confirmed by high-resolution transmission electron microscope images (HRTEM) and X-ray diffraction (XRD) spectra indicated that the phase of In₂O₃ NWs had a growth direction of [100]. X-ray photoelectron spectroscopy (XPS) was employed to obtain the chemical compositions of the ITO NWs as well as the ratio of Sn/In and oxygen concentrations. The findings indicated that low resistivity was found for ITO NWs with smaller diameters due to higher concentrations of oxygen vacancies and less incorporation of Sn atoms inside the NWs. The resistivity of NWs increases with increasing diameter due to more Sn atoms being incorporated into the NW and their reduction of the amount of oxygen vacancies. Low resistivity NWs could be achieved again due to excess Sn atoms doped into the large diameter NWs. Therefore, by optimizing the well-controlled growth of the NW diameter and interface states, we are able to tune the electrical properties of Sn-doped ITO NWs.
