Automated microfluidic platform for studies of carbon dioxide dissolution and solubility in physical solvents

Abstract

We present an automated microfluidic (MF) approach for the systematic and rapid investigation of carbon dioxide (CO₂) mass transfer and solubility in physical solvents. Uniformly sized bubbles of CO₂ with lengths exceeding the width of the microchannel (plugs) were isothermally generated in a co-flowing physical solvent within a gas-impermeable, silicon-based MF platform that is compatible with a wide range of solvents, temperatures and pressures. We dynamically determined the volume reduction of the plugs from images that were accommodated within a single field of view, six different downstream locations of the microchannel at any given flow condition. Evaluating plug sizes in real time allowed our automated strategy to suitably select inlet pressures and solvent flow rates such that otherwise dynamically self-selecting parameters (e.g., the plug size, the solvent segment size, and the plug velocity) could be either kept constant or systematically altered. Specifically, if a constant slug length was imposed, the volumetric dissolution rate of CO₂ could be deduced from the measured rate of plug shrinkage. The solubility of CO₂ in the physical solvent was obtained from a comparison between the terminal and the initial plug sizes. Solubility data were acquired every 5 min and were within 2–5% accuracy as compared to literature data. A parameter space consisting of the plug length, solvent slug length and plug velocity at the microchannel inlet was established for different CO₂–solvent pairs with high and low gas solubilities. In a case study, we selected the gas–liquid pair CO₂–dimethyl carbonate (DMC) and volumetric mass transfer coefficients 4–30 s⁻¹ (translating into mass transfer times between 0.25 s and 0.03 s), and Henry's constants, within the range of 6–12 MPa.
