Solvent-induced self-assembly of hydrogen bonded P4VP-perylenebisimide comb polymer

Abstract

Polymeric supramolecular assemblies were formed when an unsymmetric perylenebisimide substituted with ethylhexyl chains on one end and functionalized with 3-pentadecylphenol at the other termini (PDP-UPBI) was complexed with poly(4-vinylpyridine) (P4VP) via hydrogen-bonding interaction. The self-assembly behavior of this polymeric supramolecule poly(4-vinylpyridine)-perylenebisimide P4VP(PDP-UPBI)_1.0 was studied in solvents of varying polarity like chloroform (CHCl₃) and methylcyclohexane (MCH). Variable concentration and variable temperature proton NMR studies in CDCl₃ and deuterated 1,1,2,2-tetrachloroethane (TCE), respectively, revealed the polymeric nature of the perylenebisimide upon complexation and the high thermal stability of the self organized structures in solution. The improved solubility afforded by the complexation enabled variable temperature UV-Vis absorption studies in the non-polar solvent MCH, which indicated the existence of strong face-to-face stacked H-type aggregates. The strong fluorescence quenching in MCH also supported the identification of the nature of aggregates as co-facial H-type. Although the existence of aggregates was not very evident in dilute solutions of chloroform, the fluorescence of the P4VP(PDP-UPBI)_1.0 was quenched compared to that of PDP-UPBI. Thin spin coated films of the complex from chloroform exhibited features of rotationally displaced H-type aggregates characterized by blue shift of absorption maxima and the appearance of a new red shifted peak at 540 nm with weak aggregate emission beyond 600 nm. Morphology analysis of drop cast samples using scanning electron microscopy (SEM) and transmission electron microscopy (TEM) revealed the formation of micrometer long multilamellar nanofibers from CHCl₃ and two dimensional multilamellar nanosheets upon switching the solvent to MCH.
