Shrimp-shell derived carbon nanodots as precursors to fabricate Fe,N-doped porous graphitic carbon electrocatalysts for efficient oxygen reduction in zinc–air batteries†
Abstract
In this work, shrimp-shell derived N-doped carbon nanodots (N-CNs) as carbon and nitrogen sources are assembled into particle-like aggregates by a simple polymerization reaction of pyrrole in the presence of Fe3+ to form Fe containing N-CN/polypyrrole (PPY) composites (Fe–N-CN/PPy). The resulting composites are thermally treated by a facile pyrolysis approach under a N2 atmosphere to obtain an Fe,N-doped porous graphitic carbon (Fe-N-PGC) material. The results demonstrate that the pyrolytically converted carbon material at 800 °C (Fe-N-PGC-800) exhibits an approximately mesoporous structure with a pore size distribution centered at ∼1.97 nm and ∼2.8 nm and a surface area of 806.7 m2 g−1. As an electrocatalyst for oxygen reduction reaction (ORR) in alkaline media, Fe-N-PGC-800 shows superior ORR catalytic activity with an onset potential of −0.017 V and a limiting current density of 5.42 mA cm−2 (at −0.4 V, vs. Ag/AgCl), which is superior to that of commercial Pt/C catalysts (onset potential of −0.018 V and a limiting current density of 5.21 mA cm−2 at −0.4 V, vs. Ag/AgCl). Additionally, Fe-N-PGC-800 also exhibits good ORR activity in acidic media with an onset potential of 0.53 V and a limiting current density of 5.58 mA cm−2 (at 0.1 V, vs. Ag/AgCl), comparable to that of most reported Fe-based N-doped carbon electrocatalysts. An air cathode made from Fe-N-PGC-800 shows high performance and superior cycling durability in zinc–air batteries (gravimetric energy density of 752 Wh kg−1), comparable to that of commercial Pt/C-based batteries (gravimetric energy density of 774 Wh kg−1). This work demonstrates the feasibility of utilizing biomass as a starting material to fabricate Fe,N-doped carbon materials as high performance ORR electrocatalysts for practical application in ORR-relevant energy devices.
