Microfluidic train station: highly robust and multiplexable sorting of droplets on electric rails

Abstract

Fluorescence-activated droplet sorting (FADS) has become a widely used technique for high-throughput screening applications. However, existing methods are very sensitive to fluctuating flow rates at the sorting junction, which can be caused by the pulsing effects of mechanical pumps, droplet aggregates or the accumulation of precipitates during lengthy biological screening applications. Furthermore, existing sorting devices allow only 2-way sorting. We present here a dielectrophoretic sorting system in which the droplets are sorted along multiple electrode pairs that run parallel to the channels. This enables highly reliable sorting (no errors were detected for more than 2000 sorting events) even when inverting the relative flow rates at a 2-way sorting junction from 80 : 20 to 20 : 80. Furthermore, our toolbox is scalable: we demonstrate on the example of a triple-colour sorting experiment with a total of four decoupled electrodes that multi-way sorting is feasible.

Graphical abstract: Microfluidic train station: highly robust and multiplexable sorting of droplets on electric rails

Supplementary files

Article information

Article type
Technical Innovation
Submitted
16 Dec 2016
Accepted
16 Feb 2017
First published
17 Feb 2017
This article is Open Access
Creative Commons BY license

Lab Chip, 2017,17, 1024-1030

Microfluidic train station: highly robust and multiplexable sorting of droplets on electric rails

D. Frenzel and C. A. Merten, Lab Chip, 2017, 17, 1024 DOI: 10.1039/C6LC01544A
