High-performance quantum dot light-emitting diodes using chip-scale package structures with high reliability and wide color gamut for backlight displays

Abstract

High reliability and wide color gamut light-emitting diodes (LEDs) that use composite quantum dot films (CQDFs) protected by chip-scale package (CSP) structures are presented. CQDFs containing CdZnSeS/ZnS core–shell QDs and the K₂SiF₆:Mn⁴⁺ phosphors were mixed with silicone gel and used as color converters in the CSP QD-LEDs. The CSP QD-LEDs, used for backlight displays, transmitted through a color filter and exhibited ITU-R Recommendation BT.2020 of approximately 86% (a National Television System Committee value of 115%). Furthermore, we performed a long-term reliability analysis test on the CSP QD-LEDs for 2352 h to verify whether the optical performance of CSP QD-LEDs does not significantly degrade relative to that of a conventional plastic leaded chip carrier QD-LEDs. We implemented a highly reliable package technology that can protect the QDs, solve the moisture/oxygen problems in defective QD-LEDs, and produce a backlight source for display with a wide color gamut.
