Interplay between H2O and CO2 coadsorption and space-charge on Y-doped BaZrO3 surfaces

Abstract

The present work quantifies the equilibrium defect and adsorbate chemistry on oxide surfaces in the presence of multiple gas components at elevated temperatures and sub-surface space charge. The concentrations of chemisorbed H₂O and CO₂ as well as surface protons and oxygen vacancies were calculated for Y-doped BaZrO₃ using a thermodynamic framework with input from first-principles calculations. The overall energy of the system was minimized based on contributions from gas adsorption, interactions between defects and adsorbates, segregation of point defects and space-charge formation, as well as configurational entropy. The coverage dependent adsorption energies were found as −1.44 + 0.34Θ_H2O eV and −2.25 + 1.21Θ_CO2 eV for chemisorption of H₂O and CO₂, respectively. The interaction between the adsorbates was found to follow 1.72Θ_H2OΘ_CO2 eV. The coverage of surface protons was above 0.3 up to 1000 K under most considered conditions (0.01–1 bar H₂O, 4 × 10⁻⁴–1 bar CO₂) due to a favorable interaction with both surface hydroxide and CO₂ adsorbates. Most importantly, the results show that the coadsorption, adsorbate interactions or space-charge formation each played a major role in the obtained defect concentrations and surface coverages. Thus, the approach in this work demonstrates the importance of considering quantitatively each of these aspects in obtaining accurately the surface equilibria on complex catalytic oxides.
