Synthesis and thermoelectric properties of 2- and 2,8-substituted tetrathiotetracenes

Abstract

Reaction of elemental sulfur with 2-R¹ and 2,8-R¹,R²-substituted tetracenes (2) in refluxing DMF affords 5,6,11,12 tetrathiotetracenes (1) in good yields (74–99%) for a range of substituents where R¹,R² are: H,H (a); Me,H (b); MeO,H (c); Ph,H (d); Me,Me (e), iPr,Me (f, iPr = iso-propyl, CHMe₂), Me,MeO (g); MeO,MeO (h). The reaction rate is limited only by the solubility of the tetracene (2); 2g–h being both the least soluble and slowest reacting. At partial conversion recovered single crystalline 2g led to its X-ray structure determination. Vacuum deposited (substrate deposition temperature 300 K, pressure 7 × 10⁻⁶ mbar, source temperature 500 K) thin films from 1 (of initial 88–99% purity) show final electrical conductivities, σ_{(in plane)} from 1.40 × 10⁻⁵ S cm⁻¹ (1g) to 3.74 × 10⁻⁴ S cm⁻¹ (1b) for the resultant near pristine films; while 1d proved too involatile to be effectively sublimed under these conditions. In comparison, initially 95% pure TTT (1a) based films show σ_(in-plane) = 4.33 × 10⁻⁵ S cm⁻¹. The purities of 1a–h are highly upgraded during sublimation. Well defined micro-crystallites showing blade, needle or mossy like habits are observed in the films. The Seebeck coefficients (S_b) of the prepared 1 range from 374 (1c) to 900 (1f) μV K⁻¹ (vs. 855 μV K⁻¹ for identically prepared 95% pure TTT, 1a). Doping of films of 1f (R¹ = iPr, R² = Me) with iodine produces optimal p-type behaviour: σ_(in-plane) = 7.00 × 10⁻² S cm⁻¹, S_b = 175 μV K⁻¹. The latter's power factor (PF) at 0.33 μW m⁻¹ K⁻² is more than 500 times that of the equivalent I₂-doped TTT films (1a, R¹ = R² = H), previously regarded as the optimal material for thin film thermoelectric devices using acene radical cation motifs.
