Enhanced thermoelectric performance of Sn-doped Cu3SbS4

Abstract

Cu₃SbS₄ is an earth-abundant and low-cost alternative thermoelectric material for medium temperature applications. Tin doping into Cu₃SbS₄ yields materials with high thermoelectric performance. The electronic structure of Sn-doped Cu₃SbS₄ was studied using both hybrid density functional theory (DFT) and the quasi-particle self-consistent GW (QSGW) approach. A synthesis method involving mechanical alloying (MA) and spark plasma sintering (SPS) was employed to produce dense and single phase Cu₃SbS₄ samples with very fine grain size. Previously unreported nano-scale twins on {112} planes were observed by transmission electron microscopy (TEM). All of the samples showed very low lattice thermal conductivity, which is attributed to their microstructures. Sn was found to substitute Sb successfully in Cu₃SbS₄ and work effectively as an acceptor dopant, leading to an enhanced power factor. A maximum zT value of 0.72 at 623 K was achieved in Cu₃Sb_1−xSn_xS₄ (x = 0.05), which is comparable to the Se analogue Cu₃SbSe₄.
