Hollow spheres of CoCr2O4–Cr2O3 mixed oxides with nanoscale heterojunctions for exclusive detection of indoor xylene

Abstract

As an effective alternative to simple binary oxide chemiresistors, polynary oxides with excellent tunability of the composition and hetero-interfaces are considered as promising material platforms for designing highly selective and sensitive gas sensors. In this study, ternary spinel CoCr₂O₄ hollow spheres and CoCr₂O₄–Cr₂O₃ mixed oxide hollow spheres were prepared via one-pot ultrasonic spray pyrolysis using solutions with different cation compositions (i.e., [Cr]/[Co] = 2, 3, and 4), and their gas-sensing characteristics were investigated. The pure CoCr₂O₄ hollow spheres exhibited an unusually high response to 5 parts per million (ppm) of p-xylene (ratio of resistance to gas and air = 61.4), with negligible cross-responses to 5 ppm of ethanol, toluene, benzene, trimethylamine, ammonia, formaldehyde, and carbon monoxide. When CoCr₂O₄–Cr₂O₃ hollow spheres with discrete Cr₂O₃ nanoclusters were formed using a spray solution with a [Cr]/[Co] ratio of 3, the xylene response was enhanced to 144.1, which allows the sensitive and selective detection of sub-ppm level p-xylene. The unprecedentedly high xylene selectivity and response in the present study are explained by the gas-accessible hollow morphology, the unique catalytic activity of the ternary and mixed oxides, and the enhanced chemiresistivity due to the formation of a heterojunction between CoCr₂O₄ and Cr₂O₃. The novel ternary oxide-based gas sensors with excellent xylene-sensing performance can be used in indoor air-monitoring applications.
