Anisotropic interfacial properties of monolayer C2N field effect transistors

Abstract

Monolayer C₂N is promising for next-generation electronic and optoelectronic applications due to its appropriate band gap and high carrier efficiency. However, relative studies have been held back due to the lack of high-quality electrode contacts. Here, we comprehensively study the electronic and transport properties of monolayer C₂N with a series of electrode materials (Al, Ti, Ni, Cu, Ag, Pt, V₂C, Cr₂C and graphene) by using the nonequilibrium Green's function (NEGF) method combined with density functional theory (DFT). The monolayer C₂N forms Ohmic contacts with the Ti/Cu/Ag electrode material in both armchair and zigzag directions, whereas Ohmic contact is only formed in the zigzag direction of the C₂N–Al field effect transistor. However, the C₂N–Ni, –Pt, –V₂C, –Mo₂C, –graphene contact systems form n-type Schottky contacts in either the armchair or zigzag direction owing to the relatively strong Fermi level pinning (the pinning factor S = 0.32 in the armchair direction and S = 0.26 in the zigzag direction). By insertion of BN or graphene between the C₂N and Pt electrode in the armchair direction of contact systems, the Fermi level pinning can be effectively weakened due to the suppression of metal-induced gap states. Conspicuously, an Ohmic contact is realized in the C₂N field effect transistors with the BN–Pt electrode, suggesting a possible approach to fabricating high-performance devices. Our study is conducive to selecting appropriate electrode materials for C₂N-based field effect transistors.
