Solid-state 1D → 3D transformation of polynitrile-based coordination polymers by dehydration reaction

Abstract

In crystal structures of two chain coordination polymers [M(tcnopr3OH)₂(H₂O)₂] (M = Ni^II and Co^II; tcnopr3OH⁻ = [(NC)₂CC(O(CH₂)₃OH)C(CN)₂]⁻) based on a N,O or N,N′-bridge polynitrile ligand, the parallel chains are connected via, respectively, CN⋯H–O and O–H⋯O hydrogen bonds between uncoordinated functional groups of the ligand and coordinated water molecules. Upon heating, both solids undergo dehydration accompanied by degradation of their single crystals. Powder X-ray diffraction showed that non-isostructural triclinic single crystals transformed to isostructural monoclinic compounds. The solid-state reaction yielded 3D coordination polymers [M(tcnopr3OH)₂] (M = Ni^II and Co^II) based on a N,N′,O-connected tcnopr3OH⁻. Although previously tens of complexes based on tcnopr3OH and similar anions were synthesized and X-ray characterized, none of these contain a tridentate polynitrile ligand. Thus, this study provides evidence that solid-state reactions allow obtaining novel coordination modes of polynitrile ligands. The possible pathways for the transformation of H-bonded networks to 3D coordination polymers are discussed on the basis of the topological approach. Applicability of the topological approach to predict possible networks of solid-state reaction products based on the crystal structures of initial compounds is demonstrated.
