4 V room-temperature all-solid-state sodium battery enabled by a passivating cathode/hydroborate solid electrolyte interface

Abstract

Designing solid electrolytes for all-solid-state-batteries that can withstand the extreme electrochemical conditions in contact with an alkali metal anode and a high-voltage cathode is challenging, especially when the battery is cycled beyond 4 V. Here we demonstrate that a hydroborate solid electrolyte Na₄(CB₁₁H₁₂)₂(B₁₂H₁₂), built from two types of cage-like anions with different oxidative stability, can effectively passivate the interface to a 4 V-class cathode and prevent impedance growth during cycling. We show that [B₁₂H₁₂]²⁻ anions decompose below 4.2 V vs. Na⁺/Na to form a passivating interphase layer, while [CB₁₁H₁₂]⁻ anions remain intact, providing sufficient ionic conductivity across the layer. Our interface engineering strategy enables the first demonstration of a 4 V-class hydroborate-based all-solid-state battery combining a sodium metal anode and a cobalt-free Na₃(VOPO₄)₂F cathode without any artificial protective coating. When cycled to 4.15 V vs. Na⁺/Na, the cells feature a discharge capacity of 104 mA h g⁻¹ at C/10 and 99 mA h g⁻¹ at C/5, and an excellent capacity and energy retention of 78% and 76%, respectively, after 800 cycles at C/5 at <0.2 MPa at room temperature. Increasing the pressure to 3.2 MPa enables a discharge capacity of 117 mA h g⁻¹ at C/10 with a mass loading of 8.0 mg cm⁻², corresponding to an areal capacity close to 1.0 mA h cm⁻². The cell holds the highest average discharge cell voltage of 3.8 V and specific energy per cathode active material among all-solid-state sodium batteries reported so far, emphasizing the potential of hydroborates as electrolytes for a competitive all-solid-state battery technology.
