Facile preparation of porous sheet–sheet hierarchical nanostructure NiO/Ni–Co–Mn–Ox with enhanced specific capacity and cycling stability for high performance supercapacitors

Abstract

NiO, Ni–Co–Mn–O_x and NiO/Ni–Co–Mn–O_x on nickel foam substrates were prepared via a chemical bath deposition–calcination. The thermodynamic behavior was observed by TG/DTA. The chemical structure and composition, phase structure and microstructures were tested by XPS, XRD, FE-SEM and TEM. The electrochemical performance was measured by CV, GCD and EIS. The mechanism for formation and enhancing electrochemical performance is also discussed. Firstly, the precursors such as NiOOH, CoOOH and MnOOH grow on nickel foam substrates from a homogeneous mixed solution via chemical bath deposition. Thereafter, these precursors are calcined and decomposed into NiO, Co₃O₄ and MnO₂ respectively under different temperatures in a muffle furnace. Notably, NiO/Ni–Co–Mn–O_x on nickel foam substrates reveals a high specific capacity with 1023.50 C g⁻¹ at 1 A g⁻¹ and an excellent capacitance retention with 103.94% at 5 A g⁻¹ after 3000 cycles in 2 M KOH, its outstanding electrochemical performance and cycling stability are mainly attributed to a porous sheet–sheet hierarchical nanostructure and synergistic effects of pseudo-capacitive materials and excellent redox reversibility. Therefore, this research offers a facile synthesis route to transition metal oxides for high performance supercapacitors.
