Photoinduced swing of a diarylethene thin broad sword shaped crystal: a study on the detailed mechanism

Abstract

We report a swinging motion of photochromic thin broad sword shaped crystals upon continuous irradiation with UV light. By contrast in thick crystals, photosalient phenomena were observed. The bending and swinging mechanisms are in fact due to molecular size changes as well as phase transitions. The first slight bending away from the light source is due to photocyclization-induced surface expansion, and the second dramatic bending toward UV incidence is due to single-crystal-to-single-crystal (SCSC) phase transition from the original phase I to phase II_UV. Upon visible light irradiation, the crystal returned to phase I. A similar SCSC phase transition with a similar volume decrease occurred by lowering the temperature (phase III_temp). For both photoinduced and thermal SCSC phase transitions, the symmetry of the unit cell is lowered; in phase II_UV the twisting angle of disordered phenyl groups is different between two adjacent molecules, while in phase III_temp, the population of the phenyl rotamer is different between adjacent molecules. In the case of phase II_UV, we found thickness dependent photosalient phenomena. The thin broad sword shaped crystals with a 3 μm thickness showed no photosalient phenomena, whereas photoinduced SCSC phase transition occurred. In contrast, large crystals of several tens of μm thickness showed photosalient phenomena on the irradiated surface where SCSC phase transition occurred. The results indicated that the accumulated strain, between isomerized and non-isomerized layers, gave rise to the photosalient phenomenon.
