Synergistically optimized electrical and thermal properties by introducing electron localization and phonon scattering centers in CuGaTe2 with enhanced mechanical properties

Abstract

CuGaTe₂ based chalcopyrite materials have attracted intense research interest due to their high power factor. However, it is difficult to substantially improve the thermoelectric performance because of their high thermal conductivity. Here we simultaneously optimize their thermoelectric and mechanical properties by introducing carbon particles (CPs) into the CuGaTe₂ matrix. Firstly, as electron localization centers, the introduced carbon particles can enhance their electrical conductivity and thereby the power factor by adjusting the electrical transport properties. Secondly, the interfaces between carbon particles and the matrix can strongly scatter the heat carrying phonons and suppress their thermal conductivity, leading to ∼41% decrease in lattice thermal conductivity at 873 K. The highest ZT value (∼1.0@873 K) is obtained for CuGaTe₂ + 0.5 wt.% CPs, which is ∼28% larger than that of pure CuGaTe₂. Thirdly, the softer carbon particles can simultaneously optimize the hardness and fracture toughness of the composites, which is beneficial for the techniques used in the processing of thermoelectric devices. The hardness is decreased from 4.45 to 3.82 GPa and the fracture toughness is increased from 0.80 to 1.10 MPa m^1/2 after introducing 0.5 wt.% CPs into the CuGaTe₂ matrix, respectively. All results indicate that the incorporation of carbon particles is a very promising approach for improving the thermoelectric and mechanical properties of CuGaTe₂.
