Controlling the fractal dimension in self-assembly of terpyridine modified insulin by Fe2+ and Eu3+ to direct in vivo effects

Abstract

Metal ion-induced self-assembly (SA) of proteins into higher-order structures can provide new, dynamic nano-assemblies. Here, the synthesis and characterization of a human insulin (HI) analog modified at Lys^B29 with the tridentate chelator 2,2′:6′,2′′-terpyridine (Tpy) is described. SA of this new insulin analog (Lys^B29Tpy-HI) in the presence of the metal ions Fe²⁺ and Eu³⁺ at different concentrations was studied in solution by fluorescence luminescence and CD spectroscopy, dynamic light scattering, and small-angle X-ray scattering, while surface assembly was probed by AFM. Unique oligomerization was observed in solution, as Fe²⁺ yielded small magenta-colored discrete non-native assemblies, while Eu³⁺ caused the formation of large fractal assemblies. Binding of both metal ions to Tpy was demonstrated spectroscopically, and emission lifetime experiments revealed a distinct Eu³⁺ coordination geometry that included two water molecules. SAXS suggested that Lys^B29Tpy-HI with Fe²⁺ oligomerized to a discrete, roughly octameric species, while Lys^B29Tpy-HI with Eu³⁺ gave very large assemblies that could be modelled as fractals. The fractal dimensionality increased with the Eu³⁺ concentration. We propose that this is a consequence of Eu³⁺ binding to both Tpy and to free carboxylic acid groups on the insulin surface. Lys^B29Tpy-HI maintained insulin receptor affinity, and showed extended blood glucose lowering and plasma concentration after subcutaneous injection in rats. The combination of metal ion directed SA and native SA provides control of nano-scale fractal dimensionality and points towards use in therapeutics.
