Preparation of poly(ionic liquid@MOF) composite monolithic column and its application in the online enrichment and purification of tectochrysin in medicinal plants

Abstract

Herein, a poly(ionic liquid@MOF) composite monolithic column was prepared via in situ radical polymerization using ionic liquid (1-allyl-3-methylimidazolium hexafluorophosphate) and MOF (derivatized UIO66-2COOH) as copolymer monomers. The composite monolithic column was characterized via scanning electron microscopy (SEM), nitrogen adsorption–desorption isotherms and mercury intrusion porosimetry. Subsequently, the composite monolithic column combined with high performance liquid chromatography (HPLC) was used as a solid-phase extraction (SPE) absorbent for online purification and enrichment of tectochrysin in medicinal plants. The results indicated that the addition of the ionic liquid and MOF not only increased the surface area but also increased the adsorption capacity of the monolith for tectochrysin. The method showed good linearity in the concentration range of 0.01–500 μg mL⁻¹. The calibration equation was y = 2154.6x − 8.3785 and the limit of detection (LOD, S/N = 3) and the limit of quantification (LOQ, S/N = 10) were 3.33 ng mL⁻¹ and 10 ng mL⁻¹, respectively. The relative standard deviation (RSD) of the intra-day and inter-day precision was less than 2.62%, the RSD of inter-column was less than 3.16%, and the recoveries ranged from 100.58% to 105.00%. Thus, results showed that this method is simple, accurate and convenient for the online enrichment and purification of tectochrysin from medicinal plants.
