A hybrid GaN/Ga2O3 structure anchored on carbon cloth as a high-performance electrode of supercapacitors

Abstract

A hybrid structure of GaN/Ga₂O₃ microrods was fabricated on carbon cloth (CC) using a hydrothermal process combined with a high-temperature nitridation followed by an air annealing process. By elevating the post-annealing temperature to 500 °C, both electron density (N_D) and specific capacitance (C_a) of the composite electrode were significantly enhanced. Symmetric SCs assembled with GaN/CC-500 showed great potential in both 1 M H₂SO₄ aqueous solution and a PVA–H₂SO₄ gel-like electrolyte. The aqueous symmetric GaN/CC-500 SC exhibited an excellent capacitance (1301.20 mF cm⁻², 0.5 mA cm⁻²), high rate capability (75.23% of capacitance retention at 10 mA cm⁻²), outstanding cycling stability (77.27% of capacitance retention after 20 000 cycles, 10 mA cm⁻²), and large energy storage capability (27.53 μW h cm⁻² of energy density, 0.10 mW cm⁻² of power density). All-solid-state symmetric GaN/CC-500 SC also manifested a high capacitance (1183.35 mF cm⁻², 0.5 mA cm⁻²) and good rate capability (53.98% capacitance retention, 10 mA cm⁻²). The high electrochemical performance of the GaN/CC-500 electrode is attributed to the GaN/Ga₂O₃ hybrid structure, with α-Ga₂O₃ providing absorption/redox active sites on the surface, and the heavily oxygen-doped GaN enabling fast electron transport. The microrods with the GaN/Ga₂O₃ hybrid structure as the active material for solid SCs can deliver an energy density of 0.58 W h kg⁻¹ (3.54 mW h cm⁻³) with a power density of 154 W kg⁻¹ (0.94 W cm⁻³). The mechanism identified in this work would be helpful in designing GaN-based energy storage devices with better performances in the future.
