Issue 5, 2022

Excellent microwave absorbing performance of biomass-derived activated carbon decorated with in situ-grown CoFe2O4 nanoparticles

Abstract

In this study, in situ-grown cobalt ferrite (CoFe2O4, CF) nanoparticles on waste biomass-derived porous activated carbon (AC) were grown via a facile hydrothermal technique to develop a CF/AC nanocomposite. The nanostructure and porous morphology of the nanocomposite were confirmed by FESEM, HRTEM and BET analysis. Microwave (MW) absorption analysis in the range of 2–18 GHz revealed a drastic improvement in the MW absorption performance of the CF/AC nanocomposite. Sample FAC20, having an AC loading of 20 wt%, exhibited excellent maximum reflection loss (RLmax) of −61.86 dB (@16.08 GHz) and an effective absorption bandwidth (RL < −10 dB) of 4.02 GHz at a thickness of 1.56 mm. In contrast, sample FAC30 (@30 wt% AC loading) at 1.9 mm thickness exhibited a maximum effective absorption bandwidth of 4.47 GHz in the Ku band. This remarkable MW absorption performance originates from the combination of AC and CF, which results in high impedance matching followed by sufficient attenuation of microwaves. The presence of multiple interfaces and the complicated porous structure improved the interfacial polarisation, dielectric polarisation and magnetic loss ability of the CF/AC composite. Thus, the present investigation presents the CF/AC composite as an excellent biomass-based nanocomposite for MW absorption applications.

Graphical abstract: Excellent microwave absorbing performance of biomass-derived activated carbon decorated with in situ-grown CoFe2O4 nanoparticles

Supplementary files

Article information

Article type
Paper
Submitted
27 Nov 2021
Accepted
30 Jan 2022
First published
31 Jan 2022
This article is Open Access
Creative Commons BY license

Mater. Adv., 2022,3, 2533-2545

Excellent microwave absorbing performance of biomass-derived activated carbon decorated with in situ-grown CoFe2O4 nanoparticles

P. Negi, S. K. Joshi, H. B. Baskey, S. Kumar, A. K. Mishra and A. Kumar, Mater. Adv., 2022, 3, 2533 DOI: 10.1039/D1MA01116B

This article is licensed under a Creative Commons Attribution 3.0 Unported Licence. You can use material from this article in other publications without requesting further permissions from the RSC, provided that the correct acknowledgement is given.

Read more about how to correctly acknowledge RSC content.
