Photoactive hydrogels for pre-concentration, labelling, and controlled release of proteins

Abstract

We report a novel hydrogel for pre-concentration, fluorescent labelling, and light-triggered release of proteins for detection of low abundance biomarkers. The hydrogel was a co-polymer of acrylamide/bisacrylamide and methacrylamide attached to fluorescein isothiocyanate via a light cleavable bond and a poly(ethylene glycol) spacer arm of molecular weight of 3400 g mol⁻¹. Unlike previous work, proteins were captured by an irreversible chemical reaction rather than by non-covalent affinity binding or physical entrapment. Because the protein-reactive group was attached to fluorescein, which in turn was coupled to the hydrogel by a photocleavable bond, on release the protein was labelled with fluorescein. Our hydrogel offered a pre-concentration factor of up to 236 for a model protein, streptavidin. Each protein molecule was labelled with 85 fluorescein molecules, and 50% of the proteins in the hydrogel were released after UV exposure for ∼100 s. The proteins released from the hydrogel were captured in biotinylated microtitre plates and detected by fluorescence, allowing measurement of at least 0.01 ppm (or ∼166 pM) of protein in sample solutions. The reported hydrogel is promising for detection of low abundance proteins while being less laborious than enzyme-linked immunosorbent assay and less affected by changes in environmental conditions than label-free biosensors.
