A broadband picometer resolution visible CCD spectrometer based on virtually imaged phased array technology

Abstract

Coincidental realization of broadband spectral coverage and high resolution in one spectrometer system has always been a challenge. Here, we report the development of a high-resolution visible CCD spectrometer based on the virtually imaged phase array (VIPA) technique. By using a thin glass plate and a reflective grating, a two-dimensional cross-dispersion was realized. A broadband coverage of ∼14.94 THz and a high resolution of ∼1 GHz at 632.996 nm were achieved with a simple structure. The effects of the surface quality of VIPA etalon, the pixel size of the CCD camera, the pinhole size of the input beam, and the focal length of the imaging lens on the resolution of the spectrometer and the transverse spot size on the detector plane were considered. A comparison between the experimental results by changing the imaging lens and the theoretical calculation results proved a better simulation of these two parameters, which is a helpful contribution to the design and construction of a VIPA spectrometer. The developed spectrometer will provide a useful tool for the study of high-resolution spectroscopy and for simultaneous multi-species trace detection.
