A deep learning-based framework for battery reusability verification: one-step state-of-health estimation of pack and constituent modules using a generative algorithm and graphical representation

Abstract

As the electric vehicle market continues to surge, the proper assessment of used batteries has become increasingly important. However, current technologies for assessing used batteries, which involve separately estimating the State-of-Health (SoH) of the pack and its individual modules, require multiple times of cycling tests and lead to time inefficiency and power consumption. The proposed DeepSUGAR, a deep learning-based framework for SoH estimation using a generative algorithm based on graphical representation techniques to reveal individual module health, offers the advantage of estimating the status of internal modules replying on battery pack SoH. The cycling profiles of a simultaneously measured 14S7P pack and its constituent modules were analyzed, and a convolutional neural network (CNN) was trained by spatializing cycling curves to estimate SoH. DeepSUGAR, trained on pack data, showed outstanding performance with an RMSE of 5.31 × 10⁻³ and its applicability was validated by testing with module data, resulting in an RMSE of 7.38 × 10⁻³. Furthermore, the generated module cycling profiles from pack SoH using the deep generative model were fed into the trained CNN and showed a remarkable performance with an RMSE of 8.38 × 10⁻³. DeepSUGAR can significantly reduce power consumption, processing cost, and carbon dioxide emissions by integrating module-level diagnosis within the pack-level assessment process.
