Issue 44, 2023

Electrospinning preparation and high near-infrared temperature sensing performance of one-dimensional Y2Ti2O7:Cr3+/Yb3+ nano wire-embedded-tube structures with low Cr3+ concentrations

Abstract

One-dimensional Y2Ti2O7:Cr3+/Yb3+ nano wire-embedded-tube structures composed of an outer nanotube with an outside diameter of 180–200 nm and a wall thickness of 30–36 nm and embedded wire with a diameter of 32–36 nm were fabricated via a simple single-nozzle electrospinning method at an air humidity of 45%. The Cr3+ content in the one-dimensional Y2Ti2O7:Cr3+/Yb3+ nanostructures is very low and accounts for approximately 0.5% of the total moles of Yb3+, Y3+, and Cr3+ ions. The energy transfer mechanism from Cr3+ to Yb3+ is systematically studied. The near-infrared luminescent properties of the one-dimensional Y2Ti2O7:Cr3+/Yb3+ nano wire-embedded-tube structures, especially the temperature sensing performance, were investigated. The one-dimensional Y2Ti2O7:Cr3+/Yb3+ nano wire-embedded-tube structures have emissions of 650–1100 nm and excellent temperature sensing properties. The maximum absolute sensitivity (Sa) and high relative sensitivity (Sr) values are 6.01–8.73%K−1 and 3.93–4.71%K−1, respectively, which are much higher than those of the previous Cr3+ and Cr3+/RE3+ co-doped near-infrared phosphors and other up-conversion phosphors doped by RE3+ ions.

Graphical abstract: Electrospinning preparation and high near-infrared temperature sensing performance of one-dimensional Y2Ti2O7:Cr3+/Yb3+ nano wire-embedded-tube structures with low Cr3+ concentrations

Supplementary files

Article information

Article type
Paper
Submitted
12 May 2023
Accepted
20 Oct 2023
First published
23 Oct 2023

J. Mater. Chem. C, 2023,11, 15669-15681

Electrospinning preparation and high near-infrared temperature sensing performance of one-dimensional Y2Ti2O7:Cr3+/Yb3+ nano wire-embedded-tube structures with low Cr3+ concentrations

Z. Han, H. Yu, X. Gao, B. Chen and J. Sun, J. Mater. Chem. C, 2023, 11, 15669 DOI: 10.1039/D3TC01658G
