Re-injection off-axis integrated cavity output spectroscopy for the simultaneous detection of N2O, H2O and CO with a mid-infrared QCL laser

Abstract

Off-axis integrated cavity output spectroscopy (OA-ICOS) has attracted much interest because it potentially allows highly sensitive field measurements with robust optical alignment. In this paper, a novel instrument that employs a high-finesse optical cavity as an absorption cell has been developed for sensitive measurements of multi-component gases N₂O, H₂O and CO in the atmosphere based on a mid-infrared quantum cascade laser (QCL) and OA-ICOS. In order to improve the energy utilization and increase the signal-to-noise ratio (SNR) of the signal, a new type of optical path structure of the laser re-injection method is adopted. Furthermore, the system performance can be effectively improved by using a new intervention method of injecting radio frequency (RF) white noise into a laser driver to suppress cavity mode noise and combining the wavelength modulation method (WMS). We compared the sensitivity of the second harmonic signal demodulation between the re-injection method and the standard OA-ICOS, and the SNR increased by 2.68 times compared to the latter. Analysis of the spectral measurements with Allan variance indicates that within an integration time of 1 s, the measurement accuracy of N₂O, H₂O, and CO is 6.71 ppb, 13.945 ppm, and 1.81 ppb, respectively, and within an integration time of 820 s, the measurement accuracy of N₂O, H₂O, and CO can be further improved to 1.26 ppb, 2.089 ppm, and 172 ppt, respectively. Our approach represents an underlying analytical method that provides guidelines for monitoring of representative gases in the atmosphere, industrial processes, emergency safety, etc.
