Ultrawide linear range, high sensitivity, and large-area pressure sensor arrays enabled by pneumatic spraying broccoli-like microstructures

Abstract

Large-area pressure sensor arrays with a wide linear response range and high sensitivity are beneficial to map the inhomogeneous interface pressure, which is significant in practical applications. Here, we demonstrate a pneumatic spraying method to prepare large-area microstructure films (PSMF) for high performance pressure sensor arrays. The sprayed surface morphology is designable by controlling the spraying parameters. It is worth noting that the constructed “broccoli” like morphology with a swollen top and shrunken bottom inspired a new mechanism to enlarge the linear response range by decreasing the series resistance with pressure increasing. At the same time, the pneumatic sprayed “broccoli” has a rough surface due to droplet stacking, which reduces the initial current effectively. Hence, the sensor achieves a 10 000 kPa ultrawide linear response range with a high sensitivity (98.71 kPa⁻¹), and low detection (5 Pa). The prepared sensor has a small static response error (4.4%) and 5000 cycle full-range dynamic response durability. Finally, the constructed sensor arrays can distinguish the pressure distribution in different ranges clearly, which indicates a great potential in health care, motion detection, and the tire industry.
