Unravelling the atomistic mechanisms underpinning the morphological evolution of Al-alloyed hematite

Abstract

Hydrothermal synthesis based upon the use of Al3+ as the dopant and/or ethanol as the solvent is effective in promoting the growth of hematite into nanoplates rich in the (001) surface, which is highly active for a broad range of catalytic applications. However, the underpinning mechanism for the flattening of hematite crystals is still poorly comprehended. To close this knowledge gap, in this work, we have attempted intensive computational modelling to construct a binary phase diagram for Fe2O3–Al2O3 under typical hydrothermal conditions, as well as to quantify the surface energy of hematite crystal upon coverage with Al3+ and ethanol molecules. An innovative coupling of density functional theory calculation, cluster expansion and Monte Carlo simulations in analogy to machine learning and prediction was attempted. Upon successful validation by experimental observation, our simulation results suggest an optimum atomic dispersion of Al3+ within hematite in cases when its concentration is below 4 at% otherwise phase separation occurs, and discrete Al2O3 nano-clusters can be preferentially formed. Computations also revealed that the adsorption of ethanol molecules alone can reduce the specific surface energy of the hematite (001) surface from 1.33 to 0.31 J mβˆ’2. The segregation of Al3+ on the (001) surface can further reduce the specific surface energy to 0.18 J mβˆ’2. Consequently, the (001) surface growth is inhibited, and it becomes dominant after the disappearance of other surfaces upon their continual growth. This work provides atomistic insights into the synergistic effect between the aluminium textural promoter and the ethanol capping agent in determining the morphology of hematite nanoparticles. The established computation approach also applies to other oxide-based catalysts in controlling their surface growth and morphology, which are critical for their catalytic applications.

Graphical abstract: Unravelling the atomistic mechanisms underpinning the morphological evolution of Al-alloyed hematite

Supplementary files

Article information

Article type
Paper
Submitted
13 Nov 2023
Accepted
04 Feb 2024
First published
05 Feb 2024

Nanoscale, 2024,16, 5976-5987

Unravelling the atomistic mechanisms underpinning the morphological evolution of Al-alloyed hematite

J. Gu, S. Yang, J. Z. Liu and L. Zhang, Nanoscale, 2024, 16, 5976 DOI: 10.1039/D3NR05765H
