Study on the preparation and n-heptane isomerization performance of MoOx-Pd/Ce-MCM-48 catalyst

Abstract

A Ce-MCM-48 molecular sieve was prepared by the hydrothermal synthesis method. Using Ce-MCM-48 as the support, a series of MoO_x Pd/Ce-M catalysts were prepared by the impregnation method by introducing MoO_x and Pd. XRD, N₂ adsorption desorption, SEM, TEM, NH₃-TPD, Py-IR, FT-IR, and ICP-MS were used to characterize the physicochemical properties. The performance of n-heptane isomerization in a micro fixed bed device was evaluated. The results showed that the synthesized Ce-MCM-48 was mesoporous, with a spherical particle morphology, a long-range ordered pore structure, weakly acidic sites on the surface, and an increase of B and L acids. The 2% MoO_x-Pd/Ce-M catalyst was used for the probe reaction of n-heptane hydroisomerization; when the reduction temperature was 400 °C, the reduction time was 2 hours, the reaction temperature was 300 °C, the WHSV was 7.6 h⁻¹, the conversion rate was 58.7%, the selectivity was 91.2%, and the maximum yield was 53.5%. The product distribution of multiple C7 isomers increased the selectivity of multi branched isoheptane. The addition of an appropriate amount of MoO_x would improve the performance of n-heptane isomerization.
