3D flower-like bimetallic Ni–Co metal–organic framework as an electrocatalyst for the oxygen evolution reaction

Abstract

The rational design and facile preparation of a catalyst with high activity, strong durability and low consumption for the oxygen evolution reaction (OER) is an ongoing challenge in water splitting to generate clean and renewable H₂ fuel. Herein, bimetallic metal–organic frameworks (MOFs) with a uniform morphology, controlled metal ratio and low crystallinity were constructed using a simple and reliable one-step solvothermal method. The three-dimensional (3D) flower-like MOF (F-Ni1Co4-BTC) with a Ni to Co molar ratio of 1 : 4 coordinated with 1,3,5-benzenetricarboxylic acid exhibited excellent OER catalytic activity compared with its corresponding counterparts, which can be attributed to the establishment of the exquisite morphology, the proportion of the dual-metal center, and the formation of active intermediates. Furthermore, when F-Ni1Co4-BTC was directly grown on carbon cloth (F-Ni1Co4-BTC/CC), it achieved an obvious improvement in electrochemical performance, affording a low overpotential of 292 mV at a current density of 10 mA cm⁻², a small Tafel slope (48 mV dec⁻¹), and excellent mechanical durability in an alkaline electrolyte, which is due to the integrated electrode attained richer active sites and faster electron transfer rate with the introduction of highly conductive carbon cloth. Our work offers a promising strategy to tailor the properties of bimetallic MOFs and the possibility of highly efficient earth-abundant catalysts for practical applications.
