Laser-induced fibers and copper phthalocyanine modified laser-induced graphene electrodes for sensitive and selective electrochemical detection of nitrite

Abstract

We have recently reported laser-induced fibers (LIF) as a promising nanomaterial that possesses good electrochemical activity and are easily manufacturable. In this paper, for the first time, the application of LIF as functionalization materials on laser-induced graphene (LIG) electrodes for the detection of nitrate is demonstrated. The as-fabricated LIF surfaces on Kapton were extracted by ultrasonication as a dispersion and were used to modify the surface of the LIG electrode. An enhancement in active surface area from 0.669 cm² for bare LIG to 0.83 cm² for LIF-modified LIG was observed. Similarly, the heterogeneous electron transfer rate increased from 0.190 to 0.346 cm s⁻¹ for LIF/LIG electrodes. The electrochemical detection of nitrite was achieved by modifying the LIG with a nanocomposite of LIF and copper phthalocyanine (CuPc). The presence of CuPc provided the desired catalytic activity towards the oxidation of nitrite, and the LIF enhanced the electron transfer to the electrode. Such a synergetic combination of the LIF embedded with CuPc enabled reaching a low limit of detection (LoD) of 0.12 μM, a large linear range from 10 to 10 000 μM and good selectivity in the presence of potential interferants. The sensor had a long shelf life of 30 days and good analytical capability to detect nitrite in mineral, tap, and groundwater. The potential of LIF is largely unexplored and the findings reported here on the fibers would open manifold opportunities for realizing novel applications.
