Electron irradiation enhanced wear resistance and hardness of polytetrafluoroethylene (PTFE)

Abstract

The surface of polytetrafluoroethylene (PTFE) bulk materials was modified by irradiation at high temperatures using a 1.2 MeV electron beam. The mass wear rate was decreased from 2.5 × 10⁻⁶ g N⁻¹ m⁻¹ to 0.08 × 10⁻⁶ g N⁻¹ m⁻¹, and the hardness was increased from 33.2 MPa to 93.9 MPa. The yield strength was increased from 12.1 MPa to 25.8 MPa and Young's modulus was enhanced from 101 MPa to 261 MPa. The use of electron beam irradiation on PTFE at high temperature is an effective modification method to significantly improve its wear resistance and hardness, and increase the elastic response range of PTFE. The chemical reaction induced by electron irradiation at high temperature changes the molecular structure of the PTFE bulk material from highly linear to a network, thus improving the surface mechanical properties of PTFE.
