Synthesis and X-ray structure analysis of cytotoxic 2-picolylamino-type Hf^IV-bis-chelated complexes

Abstract

Eight novel heteroleptic Hf^IV complexes containing differently substituted 2-picolylamino-bis-phenolate and 2,6-dipicolinic acid (Dipic) groups as chelating ligands were synthesized and characterized with yields higher than 80%. These [ONON] type Hf^IV complexes have good aqueous stability and potent anti-tumor activity against HeLa S3 (human cervical adenocarcinoma) and Hep G2 (human derived hepatoma) cells. In particular, the complexes demonstrated selective inhibitory activity against Hep G2 cells. The IC₅₀ value of the most cytotoxic complex [L₁Hf^IVDipic^4-Cl] (0.9 ± 0.4 μM) was ten-fold higher than that of cisplatin (11.2 ± 2.1 μM) on Hep G2 cells, being the most cytotoxic anti-tumor Hf^IV complex to date. Furthermore, [L₁Hf^IVDipic^4-Cl] could inhibit tumor cell migration, induce reactive oxygen species generation (particularly HO˙), loss of mitochondrial membrane potential and almost exclusive early apoptosis in HeLa S3 cells. [L₁Hf^IVDipic^4-Cl] exhibited rapid cellular uptake by HeLa S3 cells, and when in aqueous media, these Hf^IV complexes slowly hydrolyzed, releasing non-toxic phenolato ligands as the product of hydrolysis. Overall, these rare earth complexes, particularly [L₁Hf^IVDipic^4-Cl], show promising potential as novel anticancer agents with significant efficacy against human liver cancer cells and favorable selectivity profiles for further therapeutic development.

---

Introduction

Titanocene dichloride ([Cp₂Ti^IVCl₂], TDC) and budotitane (bis-(1-phenyl-1,3-butanedione)Ti^IV) were the first group 4 metal complexes with anti-tumor activity reported in the 1980s.^1,2 Both entered clinical trials but failed due to limited aqueous stability and undefined mechanisms of action. Still, they opened a new chapter in medicinal chemistry as a large number of their derivatives have been synthesized and evaluated for anti-tumor efficacy over the last decades.³ In 2007, Tshuva et al. reported a di-amino-phenolato Ti^IV bis-alkoxyl complex that exhibited significantly improved aqueous stability and stronger anti-tumor activity than TDC,⁴ thus laying the foundation for a new generation of anti-tumor Ti^IV complexes.^5,6 Following studies, by us^7,8 and others,^9,10 it was shown that the aqueous stability can be further improved by replacing the labile alkoxy groups on Ti^IV with additional chelators. These can either be part of the phenolato backbone (N-hydroxyethyl), resulting in homoleptic complexes, or achieved by introducing an additional chelator (2,6-dipicolinic acid, Dipic), resulting in heteroleptic Ti^IV complexes. These heteroleptic Ti^IV complexes have significantly enhanced kinetic stability and anti-tumor activity. The anti-tumor active species formed by hydrolysis,¹¹ the in vivo anti-tumor efficacy¹² and the mechanism of action were subsequently investigated.^13,14

In addition to their role as potential anti-tumor candidates, the above heteroleptic Ti-complexes have recently found application in tumor sensing and as tumor targeting drugs.¹⁵ A ⁴⁵Ti complex stabilized by the above heteroleptic ligand system has recently been used as a PET (positron emission tomography) tracer to visualize tumor tissue. Conjugation of a Dipic-based heteroleptic ⁴⁵Ti complex with tumor targeting PSMA (prostate specific membrane antigen) has combined chemotherapeutic effects with diagnostic features.¹⁶

Recently, we reported a post-functionalization protocol for [(Salan)Ti^IV(Dipic)]via a pallidum-catalyzed Sonogashira reaction,¹⁷ and an environmentally benign synthesis of heteroleptic bis-chelated Ti^IV complexes in green solvents within minutes.¹⁸ Since SAR (structure–activity relationship) data revealed that the phenolato “part” is crucial for the anti-tumor activity of Salan-type Ti^IV complexes,¹⁹ we further expanded the complex library to three types of phenolato ligands: [ONNO] (Salan) type, [ONON] type with a 2-picolylamino “side bridge” and [ONOO] type with an N-(2-hydroxyethyl) “side arm”. Among them, the [ONON] type Ti^IV complexes showed the strongest anti-tumor activity and low toxicity on primary cells.¹³ Despite the above achievements for anti-tumor Ti^IV complexes, the field for the other two group 4 metals, Zr (Zirconium) and Hf (Hafnium), is surprisingly underdeveloped. In particular, to the best of our knowledge, for anti-tumor Hf^IV complexes, only 10 related reports have been found.

Coordination complexes of rare earth metals, especially those of hafnium, have been mainly used in luminescent materials^20,21 and as catalysts for polymerization reactions.^22–25 Regarding bioactive Hf^IV complexes, early reports showed that hafnocene dichloride did not exhibit anti-tumor activity.²⁶ A folate–Hf^IV conjugate showed anti-bacterial and anti-fungal activity.²⁷ In contrast, McGowan et al. reported that the IC₅₀ of a tris-diphenyl β-diketonato Hf^IV complex was in the same range as that of cisplatin against HT-29 (human colorectal adenocarcinoma) and MCF-7 (Michigan Cancer Foundation-7, human breast adenocarcinoma). However, its aqueous stability was not investigated,²⁸ probably for the same reasons that budotitane failed earlier. Recently, Choi et al. reported that a Hf-MOF (metal organic framework) containing a folate moiety could generate ROS (reactive oxygen species), deregulate tumor-cell proliferation, as well as increase apoptosis.²⁹ We recently reported four Salan-type Hf^IV complexes containing Dipic derivatives as the second chelator.³⁰ The complex with Dipic substituted with Cl at position 4 showed rapid cellular uptake and induced almost exclusively apoptosis in HeLa S3 cells (human cervical adenocarcinoma). Furthermore, an oxo-bridged dimeric Hf^IV–Hf^IV complex was identified as a novel anti-tumor compound.³¹ In contrast to Hf-based nanomaterials, which have been intensively studied,^32,33 molecular Hf^IV complexes are rather scarce, with only four representatives of Hf^IV bis-chelates known to date. We report herein the synthesis and characterization of eight new Hf^IV bis-chelates with tripodal tetradentate [ONON]-type ligands, H₂L_1–4 bearing a 2-picolylamino side bridge (Scheme 1). Their in vitro anti-tumor activity and mechanism of cellular uptake, ROS production and apoptosis are also investigated and presented.

Scheme 1 Synthesis of 2-picolylamino [ONON]-type Hf^IV bis-chelates [L_1–4Hf^IVDipic] and [L_1–4Hf^IVDipic^4-Cl].

Results and discussion

Synthesis and molecular structure

The SAR (structure–activity relationship) from our previous report on phenolato Ti^IV bis-chelates indicated that the aqueous stability and anti-tumor activity of the complexes were dominated by the substitution pattern on the phenolato moiety.¹³ When the 2 position of the phenyl (phenolato) was occupied by sterically demanding groups, such as t-butyl, the stability was significantly enhanced. While cytotoxicity was maintained for 2-picolylamino and 2-hydroxyethylamino Ti^IV complexes, it disappeared for Salan Ti^IV complexes bearing the ethylenediamino linker. Less bulky substitutions such as those with methyl were important for both cytotoxicity and stability. Lighter halogen atoms, such as Cl and F, increased the cytotoxicity, whereas Br decreased it. Additionally, our previous work with Hf^IV complexes showed that the Cl atom on the Dipic co-ligand was also important, since it enhanced the compound's polarity and provided the necessary solubility in polar solvents.³⁰

Based on the above observations, ligands H₂L_1–4 containing t-butyl and methyl at the 2, 3 and 4 positions (phenyl) were synthesized, and Dipic^4-Cl was also employed as a second chelator. It is worth mentioning that 2-picolylamino ligands bearing halogens could not be converted into the corresponding Hf^IV complexes and were therefore excluded from this study. [L_1–4Hf^IVDipic^4-H,Cl] complexes were easily synthesized from Hf(OⁿBu)₄ in toluene, following our previous report,³⁰ and in good yields (>80%). The Hf^IV complexes of H₂L₂ and H₂L₃ containing t-butyl in the ortho position to the OH group could be purified directly by flash chromatography on silica gel, whereas the Hf^IV complexes of H₂L₁ and H₂L₄ are kinetically less stable and decompose on silica gel. For these, purification relied on filtration of insoluble matter and washing with toluene to remove unreacted ligands. The enhanced stability with increasing bulkiness at the ortho position is a direct consequence of steric shielding of the O–Ti bond.¹⁹ All ligands and Hf^IV complexes were characterized by the usual analytical techniques of ¹H and ¹³C NMR, FTIR, HRMS (ESI-TOF), elemental analysis and UV-vis absorption spectroscopy and details are given in the ESI.† These confirm the molecular structure of the compounds and their purity. The HPLC analyses (see the ESI†) show, for all complexes, the presence of one peak, corresponding to >99%, corroborating their high purity.

Single crystals suitable for X-ray diffraction analysis of [L₂Hf^IVDipic] and [L₂Hf^IVDipic^4-Cl] were obtained by slow crystallization in a mixed solvent consisting of dichloromethane and hexane (1 : 1) at −20 °C. The solid state ORTEP diagrams of the molecular structures are depicted in Fig. 1. The main crystallographic data and selected bond distances and angles are given in the ESI.†[L₂Hf^IVDipic] is triclinic and [L₂Hf^IVDipic^4-Cl] is monoclinic and they crystallized in P1̄ and P2_1/n space groups, respectively. The [L₂Hf^IVDipic] unit cell also contains one molecule of hexane and one molecule of H₂O. Similar to the reported [ONNO]-type (Salan) [L₅Hf^IVDipic] (L₅ = 6,6′-((ethane-1,2-diylbis(methylazanediyl))bis(methylene))bis(2,4-dimethylphenol)),³⁰ the tripodal [ONON]-type ligand occupies one face of a pseudo-octahedron with Dipic occupying the remaining cis-positions, forming a hepta-coordination sphere around the Hf^IV centre. The bond angles of O(1)–Hf–O(2) (161.31° and 162.93°) and O(3)–Hf–O(4) (137.06° and 137.91°) of [L₂Hf^IVDipic] and [L₂Hf^IVDipic^4-Cl] are all smaller than those of [L₅Hf^IVDipic] (168.33° and 138.52°), due to the tripodal arrangement of L₂. However, the 2-picolylamino side bridge does not significantly affect the N(1)–Hf–N(2) angle (Table 1). Finally, the dihedral angle of the phenyl moieties in [L₅Hf^IVDipic] (78.44°) is much larger than in [L₂Hf^IVDipic] and [L₂Hf^IVDipic^4-Cl] (49.3° and 48.7°) (Fig. S3†). This rather “flat” arrangement of the phenyl rings reflects to some extent the spatial flexibility of the 2-picolylamino Hf^IV complexes.

Fig. 1 Solid state molecular structures of approximate C₂ symmetric hepta-coordinated [ONON]-type Hf^IV bis-chelates. Thermal ellipsoids are drawn at the 50% probability level. Hydrogen atoms are omitted for clarity.

Table 1 Selected bond lengths (Å) and angles (°) of [L₂Hf^IVDipic] and [L₂Hf^IVDipic^4-Cl] and a previously reported [L₅Hf^IVDipic] ³⁰

	[L2Hf^IVDipic]	[L2Hf^IVDipic^4-Cl]	[L5Hf^IVDipic]
O(1)–Hf	1.980(19)	1.998(3)	1.985(2)
O(2)–Hf	1.983(19)	1.969(3)	1.988(2)
O(3)–Hf	2.133(19)	2.156(3)	2.121(2)
O(4)–Hf	2.149(19)	2.116(3)	2.135(2)
N(1)–Hf	2.398(2)	2.402(4)	2.432(3)
N(2)–Hf	2.394(2)	2.427(4)	2.420(3)
N(3)–Hf	2.292(2)	2.282(4)	2.283(3)
O(1)–Hf–O(2)	161.31(8)	162.93(14)	168.33(9)
O(3)–Hf–O(4)	137.06(7)	137.91(12)	138.52(9)
N(1)–Hf–N(2)	71.11(8)	70.51(13)	72.67(9)

---

Additionally, PXRD (powder X-ray diffraction) was performed on [L₂Hf^IVDipic] and [L₂Hf^IVDipic^4-Cl], and the obtained spectra are consistent with the simulated ones (Fig. S4†), suggesting a pure phase for the two Hf-based crystals.

Stability and hydrolysis

The aqueous stability of the synthesized Hf^IV complexes was investigated in a mixed solvent of 1/10 (v/v) of H₂O/THF (H₂O calculated to be 1 × 10⁵ equiv.) by time-resolved UV-vis spectroscopy at 37 °C. As shown in Table 2, [L₁Hf^IVDipic], [L₁Hf^IVDipic^4-Cl], [L₄Hf^IVDipic] and [L₄Hf^IVDipic^4-Cl] decomposed rather slowly with t_1/2 (half-hydrolyzation time) calculated to be 20 h, 10 h, 20 h and 15 h, respectively. The stability characteristics of these [ONON]-type Hf^IV complexes are similar to those of the Salan Hf^IV bis-chelates, as evidenced by the complexes of L₂ and L₃ with at least one t-butyl ortho to the phenolato oxygen, which remained stable (see the ESI, Fig. S9–S16†) in the time frame studied. Moreover, the products of hydrolysis of [L₁Hf^IVDipic^4-H,Cl] and [L₄Hf^IVDipic^4-H,Cl] complexes were isolated from scaled-up reactions at 50 °C and characterized by HRMS (high resolution mass spectrometry) to be H₂L₁ and H₂L₄, respectively (Fig. S17 and S18 in the ESI†).

Table 2 Values of t_1/2 (half-hydrolyzation time) of Hf^IV complexes in a 1/10 mixture (v/v) of H₂O/THF

Entry^a	Complex	t 1/2 (h)	λ max (nm)
a Hydrolysis was followed by time-resolved UV-vis spectroscopy after mixing 3 mL of THF solution of Hf^IV complex (13.9 mmol) with 0.3 mL of H2O (0.3 mL, 1 × 10^5 equiv.) at 37 °C. b No decomposition after 2 weeks. c λ max of each Hf^IV complex was determined by UV-vis spectroscopy.
1	[L1Hf^IVDipic]	20	343
2	[L2Hf^IVDipic]	Stable^b	288
3	[L3Hf^IVDipic]	Stable^b	343
4	[L4Hf^IVDipic]	20	343
5	[L1Hf^IVDipic^4-Cl]	10	343
6	[L2Hf^IVDipic^4-Cl]	Stable^b	295
7	[L3Hf^IVDipic^4-Cl]	Stable^b	343
8	[L4Hf^IVDipic^4-Cl]	15	343

---

Cytotoxicity assay

The anti-tumor activity of the [L_1–4Hf^IVDipic^4-H,Cl] complexes and respective ligands was examined by the MTT (methylthiazolyldiphenyl-tetra-zolium bromide) assay on HeLa S3 (human cervical carcinoma) and Hep G2 (human derived hepatoma) cells with cisplatin as the reference. The IC₅₀ value for each sample was calculated as the average of the data obtained from three experiments on different days. In each replicate, all concentrations were repeated five times.

As shown in Table 3, [L₁Hf^IVDipic] (entry 1) showed reduced inhibitory activity against the two tumor cell lines compared to cisplatin (entry 15). However, the anti-tumor activity of [L₂Hf^IVDipic] (entry 2) disappeared completely. Interestingly, [L₃Hf^IVDipic] and [L₄Hf^IVDipic] demonstrated high selectivity against Hep G2 cells (entries 3 and 4). The introduction of Cl into the Dipic co-ligand significantly increased the anti-tumor activity, and [L_1–4Hf^IVDipic^4-Cl] all showed anti-tumor activity in the low micromolar range against the two tumor cell lines, in some cases higher than cisplatin (entries 5–8). Furthermore, all Dipic^4-Cl complexes are more cytotoxic to Hep G2 than to HeLa S3 cancer cells, and among them [L₁Hf^IVDipic^4-Cl] is the most cytotoxic complex (IC₅₀: 2.2 ± 0.1 μM on HeLa S3; 0.9 ± 0.4 μM on Hep G2). Its IC₅₀ value is comparable to the cytotoxic Salan type, [L₅Hf^IVDipic^4-Cl] ³⁰ (entry 9), and to the structurally related Ti^IV complex, [L₂Ti^IVDipic].¹³ The ligands H₂L_1–4, Dipic and Dipic^4-Cl were tested separately for cytotoxicity, and except for H₂L₁ and H₂L₄, which have partial activity on HeLa S3 cells in the concentration range of 1 × 10⁻⁷ μM to 1 × 10⁻⁵ μM, the others were all non-toxic (entries 10–14).

Table 3 IC₅₀ values (μM) obtained by the MTT assay in HeLa S3 and Hep G2 cells, after 48 h of incubation

Entry	Complex	HeLa S3	Hep G2
a Partially active on HeLa S3 cells, see ESI.†
1	[L1Hf^IVDipic]	15.1 ± 2.7	31.8 ± 9.8
2	[L2Hf^IVDipic]	Non-toxic	Non-toxic
3	[L3Hf^IVDipic]	Non-toxic	44.3 ± 0.1
4	[L4Hf^IVDipic]	Non-toxic	38.4 ± 18.6
5	[L1Hf^IVDipic^4-Cl]	2.2 ± 0.1	0.9 ± 0.4
6	[L2Hf^IVDipic^4-Cl]	14.4 ± 2.2	4.3 ± 1.5
7	[L3Hf^IVDipic^4-Cl]	17.3 ± 5.1	3.9 ± 1.4
8	[L4Hf^IVDipic^4-Cl]	7.3 ± 4.5	2.1 ± 0.6
9	[L5Hf^IVDipic^4-Cl]	1.5 ± 0.3	6.7 ± 1.4
10	H2L1	Non-toxic^a	Non-toxic
11	H2L2	Non-toxic	Non-toxic
12	H2L3	Non-toxic	Non-toxic
13	H2L4	Non-toxic^a	Non-toxic
14	Dipic and Dipic^4-Cl	Non-toxic	Non-toxic
15	Cisplatin	3.5 ± 0.4	11.2 ± 2.1

---

From the above results, we can conclude that the 2-picolylamino Hf^IV complexes containing Dipic^4-Cl generally have higher anti-tumor activity than the reported Salan-type Hf^IV bis-chelates and cisplatin against Hep G2 cells, and that [L₁Hf^IVDipic^4-Cl] performs better than cisplatin in HeLa S3 cells.

Structure–activity relationship

The structure–activity (stability) relationship of the phenolato ([ONON] and [ONNO]-type) Hf^IV bis-chelates is summarized in Fig. 2. The Hf^IV bis-chelates containing Dipic as co-ligand generally exhibit low molecular polarity, resulting in poor solubility in DMSO. The use of Dipic^4-Cl significantly enhances the molecular polarity leading to better solubility and good cytotoxicity. The Hf^IV complexes bearing phenolato(t-butyl) moieties demonstrated good aqueous stability but insufficient anti-tumor activity. The [ONNO] and [ONON]-type Hf^IV complexes containing non-bulky substituents, such as methyl at either the 2 or 3 positions of phenolato, generally showed good cytotoxicity. In comparison to the [ONNO]-type Hf^IV complexes, which selectively inhibit the growth of HeLa S3 cells, the [ONON]-type Hf^IV complexes are more prone to inhibit Hep G2 cells. Furthermore, neither methyl nor H at the phenolato-2 position has a significant effect on the aqueous stability.

Fig. 2 Structure–activity relationship of [ONON]-type and [ONNO]-type Hf^IV bis-chelates.

Apoptosis assay

Since [L₁Hf^IVDipic^4-Cl] was the complex with the lowest IC₅₀ values, it was selected for studies on the mechanism of action. First, [L₁Hf^IVDipic^4-Cl] was subjected to apoptotic analysis using the Annexin V-FITC/PI apoptosis assay kit. HeLa S3 cells were used for direct comparison with the [ONNO]-type Hf^IV complex, [L₅Hf^IVDipic^4-Cl].³⁰ Cells were treated with 1 × 10⁻² μM, 1 μM and 1 × 10² μM of [L₁Hf^IVDipic^4-Cl] for 24 h and were analyzed by flow cytometry. As depicted in Fig. S8,†[L₁Hf^IVDipic^4-Cl] could induce 17.0%, 19.6% and 23.4% apoptosis in total at the three concentrations in HeLa S3 cells. In comparison to necrosis, apoptosis leads to significantly reduced side effects and is therefore preferred for anti-tumor drugs. In our study, [L₁Hf^IVDipic^4-Cl] induced only 1.3%, 1.6% and 1.3% necrosis of HeLa S3 cells at the tested concentrations (1.4% necrotic cells observed in the control group) (Fig. 3). Next, the apoptosis levels in Hep G2 cells were investigated using [L₁Hf^IVDipic^4-Cl], [L₅Hf^IVDipic^4-Cl] and [L₂Ti^IVDipic] aiming to gain more insights into their cytotoxicity behavior (Fig. 3 and Fig. S7†). The results indicate that the three metal complexes could almost exclusively induce apoptosis in Hep G2 cells, with a percentage of apoptotic cells in dead cells of 26.9%, 17.1% and 32.3% at 1 × 10² μM, respectively (Fig. S8†). A closer look at all data also shows that [L₁Hf^IVDipic^4-Cl] and [L₅Hf^IVDipic^4-Cl] induce more early apoptosis than late apoptosis on both HeLa S3 and Hep G2 cells (detailed data are given in Table S15†), suggesting that they avoid the inflammatory responses associated with late apoptosis or necrosis. In comparison, [L₂Ti^IVDipic] is prone to inducing late Hep G2 apoptosis (early/late apoptosis: 9.6%/22.7% at 1 × 10² μM). This has already been observed for [L₅Hf^IVDipic^4-Cl] ³⁰ and [L₂Ti^IVDipic] ¹³ on HeLa S3 cells, which at 1 × 10² μM induced 30.5%(Hf)/20.8%(Ti) and 15.5%(Hf)/62.3%(Ti) of early and late apoptosis, respectively. Overall, the ability to induce early apoptosis seems to be a hallmark of Hf complexes.

Fig. 3 Quantification of necrotic (Q1), late apoptotic (Q2), early apoptotic (Q3) and viable (Q4) HeLa S3 cells (left) and Hep G2 cells (right) after 24 h of incubation with control medium, 1 × 10⁻² μM, 1 μM and 1 × 10² μM [L₁Hf^IVDipic^4-Cl].

Inhibition of cell migration

Tumor migration or invasion is a major issue that needs to be addressed in cancer therapy, since it is responsible for metastasis, which is the primary cause of cancer-related mortality. In order to preliminarily examine the metastasis inhibition ability of the new Hf^IV complexes, a wound healing assay of [L₁Hf^IVDipic^4-Cl] and the previously reported [L₅Hf^IVDipic^4-Cl] on HeLa S3 cells was performed. In brief, cells were incubated with each complex for 24 h, and the WCR (wound closure rate) was used for describing the metastasis inhibition activity (see eqn (S1)†). As depicted in Fig. 4a, the WCR of [L₁Hf^IVDipic^4-Cl] and [L₅Hf^IVDipic^4-Cl] were both concentration dependent, since at concentrations of 2 μM and 4 μM, the WCR values were 8.3% and 5.4% for [L₁Hf^IVDipic^4-Cl], and 9.5% and 7.6% for [L₅Hf^IVDipic^4-Cl], respectively (Fig. 4b; the detailed experimental procedure can be found in the ESI†), while for the control it was 14.6% at 24 h. Therefore, the results show that both complexes reduce the cellular migration of HeLa S3 cells.

Fig. 4 (a) Representative images of the wound healing assay after 0 and 24 h of treatment of HeLa S3 cells with either [L₁Hf^IVDipic^4-Cl] or [L₅Hf^IVDipic^4-Cl]. (b) Quantitative data of wound closure percentages.

Cellular uptake

Next, we performed a cellular uptake investigation of [L₁Hf^IVDipic^4-Cl] using HeLa S3 cells, following the procedure used in our previous report.³⁰ A total of 3 × 10⁻⁹ mol of [L₁Hf^IVDipic^4-Cl] (2.26 × 10⁻³ mg) was added to HeLa S3 cells, and samples taken at 10 min, 30 min, 1 h, 2 h, 24 h and 48 h were subjected to ICP-MS (inductively coupled plasma mass spectrometry) analysis for cellular Hf content. The percentages of cellular Hf in relation to total Hf were 3.55%, 4.86%, 5.97%, 7.09%, 8.22% and 8.59%, at each time point. Taking the cellular Hf amount at 48 h (46 ng) as the maximum uptake, 41.30% of the maximum Hf uptake was achieved after 10 min and 69.60% after 30 min (Fig. 5a). In comparison with [L₅Hf^IVDipic^4-Cl], which showed 61.90% (10 min) and 76.20% (1 h) of the maximum Hf uptake (42 ng, 48 h),³⁰ it can be concluded that the initial Hf uptake of [L₁Hf^IVDipic^4-Cl] is slower, but is similar or higher after one hour (Fig. 5b).

Fig. 5 (a) Cellular uptake of Hf after treating HeLa S3 cells for 10 min, 30 min, 1 h, 2 h, 24 h and 48 h with [L₁Hf^IVDipic^4-Cl] (2 μM) and [L₅Hf^IVDipic^4-Cl] (2 μM). Control group: HeLa S3 cells without treatment with [L₁Hf^IVDipic^4-Cl] or [L₅Hf^IVDipic^4-Cl], no Hf (0 ng) was detected by ICP-MS. (b) Fitted cellular uptake rate of Hf after treating HeLa S3 cells with [L₁Hf^IVDipic^4-Cl] (2 μM) and [L₅Hf^IVDipic^4-Cl] (2 μM).

Intracellular ROS assessments

Oxidative stress and accumulation of ROS (reactive oxygen species) including ˙O₂⁻ (superoxide anion), HO˙ (hydroxyl radical), ¹O₂ (singlet oxygen) and H₂O₂ (hydrogen peroxide) are closely related to tumor formation and mitosis.³⁴ ROS at higher levels can lead to cell death, including apoptosis, autophagy, necroptosis or ferroptosis, with multiple cellular targets being involved.³⁵ In this study, the ROS production induced by [L₁Hf^IVDipic^4-Cl] and [L₅Hf^IVDipic^4-Cl] in HeLa S3 cells was examined with the 2′,7′-dichlorodihydro-fluorescein diacetate (H₂DCFDA probe)³⁶ (three repeats). H₂DCFDA is not fluorescent, but after reaction with ROS, it can be transformed into DCF (2′,7′-dichlorofluorescein), which shows green emission and can be detected by fluorescence microscopy. One representative experiment is depicted in Fig. 6. We found that both [L₁Hf^IVDipic^4-Cl] and [L₅Hf^IVDipic^4-Cl] could induce ROS generation at the two tested concentrations (1 μM and 2 μM). Moreover, the fluorescence in the case of [L₁Hf^IVDipic^4-Cl] was much stronger in comparison with [L₅Hf^IVDipic^4-Cl], indicating a higher level of ROS production with the former.

Fig. 6 Fluorescence microscopic images of intracellular ROS levels in HeLa S3 cells analyzed by the H₂DCFDA probe. The green spots are cells that are stained with DCF.

In order to find what types of ROS are generated in tumor cells, and the cellular effects for which they are responsible, an in vitro ROS investigation was conducted on HeLa S3 cells by flow cytometry. HeLa S3 cells were incubated with [L₁Hf^IVDipic^4-Cl] followed by different ROS scavengers, namely NaN₃ (¹O₂ scavenger), Tiron (disodium 4,5-dihydroxybenzene-1,3-disulfonate, ˙O₂⁻ scavenger), D-mannitol (HO˙ scavenger) and Nap (sodium pyruvate, H₂O₂ scavenger). As depicted in Fig. 7, the fluorescence intensity of DCF was slightly reduced (<40%) in the NaN₃, Tiron and Nap groups when compared to the control (only with [L₁Hf^IVDipic^4-Cl]), indicating that ¹O₂, ˙O₂⁻ and H₂O₂ are not the main ROS species formed. Obvious quenching of the DCF fluorescence (<80%) was observed in the D-mannitol group, suggesting that HO˙ accounted for the majority of [L₁Hf^IVDipic^4-Cl]-induced ROS.

Fig. 7 (a) Flow cytometry investigation of intracellular ROS levels analyzed with the H₂DCFDA probe in HeLa S3 cells treated with 2.2 μM [L₁Hf^IVDipic^4-Cl] + different ROS scavengers for 24 h. (b) Fluorescence intensity of DCF in HeLa S3 cells treated with NaN₃, Tiron, D-mannitol and Nap.

Metal ions such as Cu, Fe, Mn and Ru can induce ROS generation through the Fenton reaction, the Haber–Weiss reaction, and mitochondrial dysfunction.³⁷ However, reports on how molecular Hf complexes induce ROS generation are scarce since Hf cannot easily undergo redox cycling, and is Fenton inactive. Hf loses all the outermost s and d electrons, leaving ionic sites with almost empty orbitals that are not able to catalyze oxygen-related reactions.³⁸ Hf-based materials such as nanoparticles of HfO₂ and Hf-based MOFs are RT (radio therapy) sensitive, and Hf^IV can absorb X-ray energy and convert it to high-energy electrons, which subsequently interact with H₂O to generate HO˙.^39,40 It has been shown that mitochondrial ETC (electron transport chain) activity can lead to the production of ROS, including superoxide and hydroxyl radicals. In the process, the mitochondrial ETC transfers electrons to O₂, and O₂ is reduced to ˙O₂⁻ anions, which are ultimately converted to hydroxyl radicals (HO˙).⁴¹ This mechanism may explain how ROS are generated by [L₁Hf^IVDipic^4-Cl]. Obviously, mitochondrial-related investigations are required to prove such a hypothesis.

Mitochondrial membrane potential

Most of the production and conversion of O₂ and ATP takes place in the mitochondria, through oxidative phosphorylation, and the generated ROS can cause MMP (mitochondrial membrane potential) decrease and even mitochondrial dysfunction. Hence, MMP has been identified as an indicator of mitochondrial dysfunction and early cell apoptosis.⁴² In this study, the MMP change of HeLa S3 cells treated with the two Hf^IV complexes was investigated with the mitochondrial fluorescent cyanine tracer, JC-1 (5,5′,6,6′-tetrachloro-1,1′,3,3′-tetraethylbenzimi-dazolylcarbocyanine iodide).⁴³ JC-1 demonstrates red fluorescence when the mitochondrion is healthy and the MMP is unchanged. However, JC-1 can dissociate from the mitochondrial membrane with the fluorescence changing from red to green when the MMP decreases. In this study, HeLa S3 cells were incubated with the Hf^IV complexes (at 1 μM and 2 μM) for 24 h and subsequently treated with the JC-1 staining solution. As depicted in Fig. 8, the MMP decreased in a concentration-dependent manner after treating HeLa S3 cells with [L₁Hf^IVDipic^4-Cl] and [L₅Hf^IVDipic^4-Cl]. Stronger green fluorescence could be observed for cells treated with [L₁Hf^IVDipic^4-Cl] compared to [L₅Hf^IVDipic^4-Cl], indicating that [L₁Hf^IVDipic^4-Cl] could induce more ROS generation in HeLa S3 cells and most probably is more prone to inducing mitochondria dysfunction. This is in agreement with the study made with the H₂DCFDA probe.

Fig. 8 Staining of mitochondrial membrane potential in HeLa S3 cells after 24 h of treatment with different concentrations (1 μM and 2 μM) of complexes [L₁Hf^IVDipic^4-Cl] and [L₅Hf^IVDipic^4-Cl].

Moreover, excessive ROS accumulation in mitochondria leads to structural changes that compromise their function.⁴¹ As shown in Fig. 9, a transmission electron microscopy (TEM) analysis revealed that HeLa S3 cells treated with [L₁Hf^IVDipic^4-Cl] exhibited pronounced mitochondrial damage, including atrophy and disrupted cristae. Typical apoptotic-related hyper-chromatin could be observed. In the control group, mitochondria maintained their normal tubular architecture—an intact outer membrane, clearly defined cristae, and no sign of edema or atrophy.

Fig. 9 TEM images of HeLa S3 cells incubated with [L₁Hf^IVDipic^4-Cl] (2 μM, 48 h). The images in the lower panels are enlarged from the red boxes in the upper panels. The mitochondria are highlighted by the red circles.

Conclusions

In conclusion, eight novel [ONON]-type Hf^IV bis-chelates containing tripodal-tetradentate L_1–4 and a common 2-picolylamino co-ligand were synthesized in good yields and high purity. The complexes were purified by flash chromatography or by extraction with organic solvents. Single-crystal X-ray diffraction studies indicate that these [ONON]-type Hf^IV complexes have more flexible coordination spheres than the [ONNO] (Salan)-type Hf^IV complexes. Similarly to the Salan-type Hf^IV complexes, the [ONON]-type complexes remained stable in aqueous media when t-butyl groups are located at the ortho-position of the phenolato moiety. Most [ONON]-type Hf^IV complexes showed a selective inhibitory effect against Hep G2 cells. Among them, the four complexes ([L_1–4Hf^IVDipic^4-Cl]) containing the chloro-substituted Dipic co-ligand exhibit the strongest cytotoxicity. The SAR suggests that both ligands of the heteroleptic complex are crucial for bioactivity; i.e. the substitution on the Dipic can be used to adjust the molecular polarity, leading to enhanced solubility in polar solvents and higher cytotoxicity, and methyl groups on the phenolate also increase the activity. In comparison with the Salan-type Hf^IV complexes, the cellular uptake of [ONON]-type Hf^IV complexes is initially slower, but the total Hf uptake is higher. In addition, the ROS production of [L₁Hf^IVDpic^4-Cl] is dose dependent and it outperformed [L₅Hf^IVDpic^4-Cl] (Salan type). [L₁Hf^IVDpic^4-Cl] selectively produces hydroxyl radicals (HO˙) as the major ROS. Furthermore, [L_1,5Hf^IVDpic^4-Cl] can cause mitochondrial dysfunction and MMP decrease, which may account for the ROS generation. Cell apoptosis (HeLa S3 and Hep G2) studies have provided some insight into the unexplored features of anti-tumor Hf^IV complexes. An interesting finding is that both families of Hf^IV complexes ([ONON] and [ONNO]) induce mostly early apoptosis, which is preferred because it causes less inflammation. Further investigations such as molecular modification, targeted therapy and detailed molecular mechanisms are currently underway in our laboratory.

Author contributions

Tiankun Zhao: supervision, conceptualization. Qi Zhang: methodology, writing – original draft. Jialiu Zhao: investigation, validation. Dongyu Mei: investigation, validation. Jing Ma: data curation. Isabel Correia: data curation, writing – review & editing. Zhongduo Yang: writing – review & editing. Sa-Hyun Kim: resources, formal analysis. Thomas Huhn: supervision, conceptualization.

Data availability

CCDC 2390816 ([L₂Hf^IVDipic]) and 2390817 ([L₂Hf^IVDipic^4-Cl]).† Supplementary data associated with this article can be found in the online version.†

Conflicts of interest

The authors declare no conflict of interest.

Acknowledgements

We are grateful to the Gansu College Teacher Innovation Project (2025A-035); the Gansu Technological Innovation Guidance Plan (24CXJA005); the National Natural Science Foundation of China (No. 22267011); and the project of the Bureau of Science and Technology of Lanzhou (2023-RC-43) for the funding of this project. The support provided by China Scholarship Council (CSC) during a visit of T. Zhao to University of Lisbon is acknowledged. I. C. thanks Fundação para a Ciência e a Tecnologia (FCT) through projects UIDB/00100/2020 (https://doi.org/10.54499/UIDB/00100/2020), UIDP/00100/2020 (https://doi.org/10.54499/UIDP/00100/2020), and LA/P/0056/2020 (https://doi.org/10.54499/LA/P/0056/2020). The authors thank Dr Xianggao Meng from Central China Normal University for useful discussion on the X-ray analysis.
