A μL-scale micromachined microbial fuel cell having high power density

Abstract

We report a MEMS (Micro-Electro-Mechanical Systems)-based microbial fuel cell (MFC) that produces a high power density. The MFC features 4.5-μL anode/cathode chambers defined by 20-μm-thick photo-definable polydimethylsiloxane (PDMS) films. The MFC uses a Geobacter-enriched mixed bacterial culture, anode-respiring bacteria (ARB) that produces a conductive biofilm matrix. The MEMS MFC generated a maximum current density of 16 000 μA cm⁻³ (33 μA cm⁻²) and power density of 2300 μW cm⁻³ (4.7 μW cm⁻²), both of which are substantially greater than achieved by previous MEMS MFCs. The coulombic efficiency of the MEMS MFC was at least 31%, by far the highest value among reported MEMS MFCs. The performance improvements came from using highly efficient ARB, minimizing the impact of oxygen intrusion to the anode chamber, having a large specific surface area that led to low internal resistance.
