Synthesis, properties, and top-gated metal–oxide–semiconductor field-effect transistors of p-type GaSb nanowires

Abstract

High-quality GaSb nanowires (NWs) have been synthesized via chemical vapor deposition. The as-synthesized NWs have a zincblende structure with growth direction along a 〈011〉 direction. Raman spectrum of the GaSb NWs consists of two peaks, corresponding to the LO and TO phonon modes, respectively. The temperature dependence of the photoluminescence spectra shows a blue-shift as the temperature decreases from 300 to 13 K. The electrical properties of the GaSb NWs are investigated over a wide range of temperatures from 25 mK to 291 K. The results show that the GaSb NWs exhibit excellent p-type transistor performance at low temperatures (<40 K). The room-temperature hole density and mobility were found to be ∼2.2 × 10¹⁸ cm⁻³ and ∼14.2 cm² V⁻¹ s⁻¹, respectively. The Schottky contact characteristics were observed and the barrier height was found to be ∼14 meV. Our results show that the GaSb NWs could be used as building blocks for emerging p-type nanoelectronic devices in extremely low temperature environments.
