Conversion of porous anodic Al2O3 into freestanding, uniformly aligned, multi-wall TiO2 nanotube arrays for electrode applications

Abstract

A combined conformal coating and gas/solid reaction process has been used for the first time to convert porous anodic alumina templates into robust, freestanding, multi-wall titania nanotube (MWTNT) arrays that resist appreciable nanotube bundling upon drying. A sol–gel infiltration process was first used to apply a thin conformal titania coating to the alumina templates. After selective etching to generate a gap between the template and the titania coating, exposed alumina was converted into nanocrystalline titania via reaction with titanium tetrafluoride gas and then with humid oxygen. After selective dissolution of residual aluminum-bearing phases and drying, freestanding, non-agglomerated, well-aligned MWTNT arrays were generated (i.e., with coating-derived inner titania tubes resting inside reaction-derived outer titania tubes). When incorporated as aligned electrodes in dye-sensitized solar cells, the dye loading and power conversion efficiencies were higher by factors of 2.2 and 1.8, respectively, than for solar cells with single-wall titania nanotube array electrodes. By controlling the conditions used for alumina template formation, sol–gel coating, and gas/solid reaction, this hybrid process may be used to generate robust, uniformly aligned MWTNT arrays with dimensions and functional chemistries tailored for a variety of electrical, optical, chemical, or biochemical applications.
