Enhanced thermoelectric properties of screen-printed Bi0.5Sb1.5Te3 and Bi2Te2.7Se0.3 thick films using a post annealing process with mechanical pressure

Abstract

A cost-effective and large-scale thermoelectric (TE) energy harvester is becoming increasingly important for energy recovery systems such as self-powered electronics and renewable power generation. Here, we report on a TE device composed of p-type Bi_0.5Sb_1.5Te₃ and n-type Bi₂Te_2.7Se_0.3 TE materials prepared using a screen-printing process, which has the advantages of low cost, scalability to large areas and the ability to form a flexible TE generator. The TE properties of the screen-printed TE thick films were optimized via subsequent annealing with mechanical pressure. It was found that thermal annealing with the application of mechanical pressure plays a key role in controlling the carrier concentration and improving the density of the TE thick films. Under optimized annealing conditions, the Bi_0.5Sb_1.5Te₃ (p-type) thick film had a ZT of 0.89 and a density of 5.67 g cm⁻³ while the Bi₂Te_2.7Se_0.3 (n-type) thick film had a ZT of 0.57 and a density of 5.68 g cm⁻³ at room temperature. TE generators composed of 72 and 200 couples were fabricated with these thick films. The output power of the device composed of 72 couples was 0.1 W for a temperature difference (ΔT) of 28 K. Another device with 200 couples generated 0.31 W of electric power for the same ΔT.
