Na–Ga–Si type-I clathrate single crystals grown via Na evaporation using Na–Ga and Na–Ga–Sn fluxes

Abstract

Single crystals of a Na–Ga–Si clathrate, Na₈Ga_5.70Si_40.30, of size 2.9 mm were grown via the evaporation of Na from a Na–Ga–Si melt with the molar ratio of Na : Ga : Si = 4 : 1 : 2 at 773 K for 21 h under an Ar atmosphere. The crystal structure was analyzed using X-ray diffraction with the model of the type-I clathrate (cubic, a = 10.3266(2) Å, space group Pmn, no. 223). By adding Sn to a Na–Ga–Si melt (Na : Ga : Si : Sn = 6 : 1 : 2 : 1), single crystals of Na₈Ga_xSi_46−x (x = 4.94–5.52, a = 10.3020(2)–10.3210(3) Å), with the maximum size of 3.7 mm, were obtained via Na evaporation at 723–873 K. The electrical resistivities of Na₈Ga_5.70Si_40.30 and Na₈Ga_4.94Si_41.06 were 1.40 and 0.72 mΩ cm, respectively, at 300 K, and metallic temperature dependences of the resistivities were observed. In the Si L_2,3 soft X-ray emission spectrum of Na₈Ga_5.70Si_40.30, a weak peak originating from the lowest conduction band in the undoped Si₄₆ was observed at an emission energy of 98 eV.
