Preparation, electronic structure of gadolinium oxyhydride and low-energy 5d excitation band for green luminescence of doped Tb3+ ions

Abstract

Oxyhydride compounds of GdHO and GdHO:Tb³⁺ were successfully prepared by solid state reaction of GdH₃, Gd₂O₃ and Gd₂O₃:Tb³⁺ under a H₂ atmosphere. XRD analysis suggests that GdHO has a cubic fluorite structure (space group Fmm, lattice parameter a = 5.38450(4) Å for GdHO and 5.38523(6) Å for GdHO:Tb), which is different from the tetragonal fluorite-like superstructure for previously reported LnHO (Ln = La, Ce, Pr and Nd) (space group P4/nmm) materials. The prepared GdHO:Tb³⁺ shows photoluminescence bands in the range between 470 and 650 nm, which are attributed to Tb³⁺:⁵D₄ → ⁷F_J transitions. In the photoluminescence excitation spectrum, a broad 4f–5d band of Tb³⁺ was clearly observed at around 310 nm, which is one of the lowest 5d energy positions compared with other Tb³⁺-doped compounds. This shift may be caused by partially coordinated hydride ions with strong covalency around Tb³⁺, which cause a large nephelauxetic effect and crystal field splitting. The lifetime of Tb³⁺:⁵D₄ is almost unchanged from 83 to 500 K and decreases above 500 K. The thermal luminescence quenching of the ⁵D₄ → ⁷F_J transition is caused by a thermally activated crossover to the ground state through the 5d energy state. The band gap energy of GdHO (5.39 eV) was smaller than that of cubic and monoclinic Gd₂O₃ (5.93 and 6.10 eV, respectively). Based on the constructed vacuum referred binding energy diagram and DFT calculation, the top of the valence band (VB) energy of GdHO is much higher than that of cubic and monoclinic Gd₂O₃ due to the higher energy level of the hydride 1s orbital than that of the oxide 2p orbital.
