Issue 9, 2021

Compatibility assessment of solid ceramic electrolytes and active materials based on thermal dilatation for the development of solid-state batteries

Abstract

Assembling an all ceramic solid-state battery (ACSSB) using inorganic oxide electrolytes is challenging. The battery must have a continuous layered structure with a thin dense electrolyte separator and interfaces between active material (AM) and ceramic electrolytes (CE) must be optimized within the electrodes to minimize polarization. This is generally achieved using high temperature processing. Selecting suitable AM and CE materials is a complex task that requires a thorough knowledge of the electrochemical behavior of each material in addition to a deep understanding of the thermal and chemical compatibility with other components of the cell. Mismatched thermal expansion coefficients (TECs) of the various layers and materials in the device can lead to cracks during the sintering step and upon cooling that dramatically affect the battery performance. Moreover, it must be certain that no reaction occurs between active materials and electrolytes in the sintering temperature range. These are two key parameters to address for the development of all ceramic solid-state batteries. High temperature x-ray diffraction (HT-XRD) has been used to determine TECs of various well-known oxide AM and CE up to 1000 °C. It is shown that TECs of typical CEs vary between −1 × 10−5 K−1 to 4 × 10−5 K−1 but still remain more stable than that of conventional AMs, which are higher on average. On the basis of TEC, lower mismatch is found for different couples. Chemo-thermal compatibility is then investigated for couples with LiNi0.5Mn1.5O4 (LNMO) material. It is determined that mixing Li0.33La0.55TiO3 (LLTO) with LNMO might be an interesting avenue for sintering ACSSB.

Graphical abstract: Compatibility assessment of solid ceramic electrolytes and active materials based on thermal dilatation for the development of solid-state batteries

Supplementary files

Article information

Article type
Paper
Submitted
28 Sep 2020
Accepted
21 Mar 2021
First published
22 Mar 2021
This article is Open Access
Creative Commons BY license

Mater. Adv., 2021,2, 2989-2999

Compatibility assessment of solid ceramic electrolytes and active materials based on thermal dilatation for the development of solid-state batteries

M. Bertrand, S. Rousselot, D. Aymé-Perrot and M. Dollé, Mater. Adv., 2021, 2, 2989 DOI: 10.1039/D0MA00743A

This article is licensed under a Creative Commons Attribution 3.0 Unported Licence. You can use material from this article in other publications without requesting further permissions from the RSC, provided that the correct acknowledgement is given.

Read more about how to correctly acknowledge RSC content.
