Issue 18, 2021

Superior and stable ferroelectric properties of hafnium-zirconium-oxide thin films deposited via atomic layer deposition using cyclopentadienyl-based precursors without annealing

Abstract

HfO2-based ferroelectric thin films deposited via atomic layer deposition have been extensively studied as promising candidates for next-generation ferroelectric devices. The conversion of an amorphous Hf1−xZrxO2 film to the ferroelectric phase (non-centrosymmetric orthorhombic phase) has been achieved through annealing using a post-thermal process. However, in this study, we present the first report of ferroelectricity of hafnium-zirconium-oxide (HZO) thin films deposited via atomic layer deposition using cyclopentadienyl-based precursors without additional post-thermal processing. By increasing the deposition temperature using a cyclopentadienyl-based cocktail precursor, the conditions of the as-deposited HZO thin film to crystallize well with an orthorhombic phase were secured, and excellent ferroelectric properties with a large remanent polarization (2Pr ∼ 47.6 μC cm−2) were implemented without crystallization annealing. The as-deposited HZO thin film possessed very stable ferroelectric properties without a wake-up effect or significant fatigue up to 106 cycles. Futhermore, we demonstrated the applicability to devices using negative capacitance and non-volatile memory characteristics. This result suggests that a new strategy can be applied to ferroelectric devices where subsequent processing temperature constraints are required, such as back-end-of-line processes and ferroelectric-based flexible device applications.

Graphical abstract: Superior and stable ferroelectric properties of hafnium-zirconium-oxide thin films deposited via atomic layer deposition using cyclopentadienyl-based precursors without annealing

Supplementary files

Article information

Article type
Paper
Submitted
10 Mar 2021
Accepted
22 Apr 2021
First published
24 Apr 2021

Nanoscale, 2021,13, 8524-8530

Superior and stable ferroelectric properties of hafnium-zirconium-oxide thin films deposited via atomic layer deposition using cyclopentadienyl-based precursors without annealing

H. Kim, M. Jung, Y. Oh, S. W. Lee, D. Suh and J. Ahn, Nanoscale, 2021, 13, 8524 DOI: 10.1039/D1NR01535D
