Sulfated zirconium oxide-decorated magnetite KCC-1 as a durable and recyclable adsorbent for the efficient removal of asphaltene from crude oil

Abstract

Sulfated zirconium oxide (ZrO₂/SO₄²⁻) as a highly durable acidic reagent was immobilized on magnetite KCC-1 nanoparticles (Fe₃O₄@SiO₂/KCC-1@ZrO₂/SO₄²⁻ NPs), and the resulting hybrid was used as a highly efficient recyclable adsorbent for the adsorption and removal of asphaltene from crude oil. The presence of ZrO₂/SO₄²⁻ groups not only promotes the adsorption capacity, but also helps recycle the adsorbents without any significant efficiency loss arising from its high chemical resistance. The results showed an obvious synergistic effect between the magnetic core (Fe₃O₄ NPs), fibrous silica (KCC-1) and the sulfated zirconium oxide groups with high correlation for asphaltene adsorption. The effective parameters in asphaltene adsorption, including initial asphaltene concentration, catalyst concentration and temperature, were investigated. Maximum adsorption occurred in the presence of 0.7 g L⁻¹ of the adsorbent, at a concentration of 2000 mg L⁻¹ of asphaltene. The asphaltene adsorption by NPs follows a quasi-second order adsorption kinetics. Asphaltene adsorption kinetics were studied by Langmuir, Freundlich, and Temkin isotherms. The prominent advantage of the adsorbent is its ability to be recovered after each adsorption by acid treatment, so that no significant reduction in adsorbent adsorption activity was observed, which can be directly attributed to the presence of ZrO₂/SO₄²⁻ groups in the hybrid.
