Enhancement in microwave absorption properties by adjusting the sintering conditions and carbon shell thickness of Ni@C submicrospheres

Abstract

The combination of traditional magnetic metal materials and dielectric carbon materials to improve microwave absorption properties has generated great interest. In this work, Ni@C submicrospheres were successfully synthesized by sintering the Ni@RF precursor and were compounded with a polymer matrix PVDF because of their excellent dielectric and mechanical properties. The outstanding microwave absorption performance was obtained by adjusting the sintering conditions and carbon shell thickness to achieve good impedance matching and high attenuation capability. It was found that the Ni@C/PVDF composite (850 °C, 3 h, d_(carbon) = 64.3 nm) shows excellent microwave absorption performance with a strong absorption value of −71.32 dB at 14.04 GHz, a broad bandwidth of 5.62 GHz and a thin matched the thickness of 1.95 mm. These findings provide a method for designing high-performance microwave absorption materials.
