Hard ferrite magnetic insulators revealing giant coercivity and sub-terahertz natural ferromagnetic resonance at 5–300 K

Abstract

The temperature behavior of the magnetic properties is crucial for the application of magnetic materials. Recently, giant room temperature coercivities (20–36 kOe) and sub-terahertz natural ferromagnetic resonance (NFMR) frequencies (160–250 GHz) were observed for single-domain M-type hexaferrites with high aluminum substitution. Herein, the temperature dependences of the magnetic properties and natural ferromagnetic resonance are studied at 5–300 K for single-domain Sr_1−x/12Ca_x/12Fe_12−xAl_xO₁₉ (x = 1.5–5.5) particles. It is shown that the samples maintain their magnetic hardness over the whole temperature range. The coercivity and NFMR frequencies have a maximum shifting to the low-temperature region with a rise in aluminum concentration. The highest coercivity of 42 kOe and the maximum NFMR frequency of 297 GHz are observed for x = 5.5 at 180 K.
