Issue 25, 2023

Stable chemical enhancement of passivating nanolayer structures grown by atomic layer deposition on silicon

Abstract

Incorporation of carrier-selective passivating contacts is on the critical path for approaching the theoretical power conversion efficiency limit in silicon solar cells. We have used plasma-enhanced atomic layer deposition (ALD) to create ultra-thin films at the single nanometre-scale which can be subsequently chemically enhanced to have properties suitable for high-performance contacts. Negatively charged 1 nm thick HfO2 films exhibit very promising passivation properties – exceeding those of SiO2 and Al2O3 at an equivalent thickness – providing a surface recombination velocity (SRV) of 19 cm s−1 on n-type silicon. Applying an Al2O3 capping layer to form Si/HfO2/Al2O3 stacks gives additional passivation, resulting in an SRV of 3.5 cm s−1. Passivation quality can be further improved via simple immersion in hydrofluoric acid, which results in SRVs < 2 cm s−1 that are stable over time (tested for ∼50 days). Based on corona charging analysis, Kelvin probe measurements and X-ray photoelectron spectroscopy, the chemically induced enhancement is consistent with changes at the dielectric surface and not the Si/dielectric interface, with fluorination of the Al2O3 and underlying HfO2 films occurring after just 5 s HF immersion. Our results show that passivation is enhanced when the oxides are fluorinated. The Al2O3 top layer of the stack can be thinned down by etching, offering a new route for fabrication of ultra-thin highly passivating HfO2-containing nanoscale thin films.

Graphical abstract: Stable chemical enhancement of passivating nanolayer structures grown by atomic layer deposition on silicon

Supplementary files

Article information

Article type
Paper
Submitted
24 Mar 2023
Accepted
31 May 2023
First published
07 Jun 2023
This article is Open Access
Creative Commons BY license

Nanoscale, 2023,15, 10593-10605

Stable chemical enhancement of passivating nanolayer structures grown by atomic layer deposition on silicon

S. L. Pain, E. Khorani, T. Niewelt, A. Wratten, M. Walker, N. E. Grant and J. D. Murphy, Nanoscale, 2023, 15, 10593 DOI: 10.1039/D3NR01374J
