Microfluidic sperm trap array for single-cell flagellar analysis with unrestricted 2D flagellar movement

Abstract

Sperm capture techniques that immobilize sperm to halt their motility are essential for the long-term analysis of individual sperm. These techniques are beneficial in assisted reproductive technologies such as intracytoplasmic sperm injection (ICSI) by allowing selective screening of sperm. However, there is a notable lack of high-throughput and non-destructive sperm capture methods that allow the flagellum to beat freely, which is crucial for accurately reflecting the behavior of unfettered, freely swimming sperm. To bridge this gap, we introduce a novel microfluidic device specifically engineered to capture sperm without restricting flagellar motion. The design utilizes sperm's innate boundary-following behavior in both 3D and 2D environments to direct them into a capture zone. Once captured, the sperm head is restrained while the flagellum remains free to exhibit natural beating patterns. Utilizing this device, we explore the effects of hyperactivating agents, temperature, and their combined influence on the dynamics of bovine sperm flagella. The unrestricted flagellar motion offered by our device yields two prominent advantages: it mirrors the flagellar behavior of free-swimming sperm, ensuring research findings are consistent with natural sperm activity, and it prevents imaging overlap between the flagellum and the capture structures, simplifying the automation of flagellar tracking and analysis. This technological advancement facilitates the collection of waveform parameters along the entire flagellum, addressing inconsistencies that have arisen in previous research due to differing measurement sites, and enabling precise extraction of sperm behavioral properties.
