A strategy for increasing the breakdown field strength beyond the experimental scaling law in yttria films†
Abstract
Aiming to increase the dielectric breakdown field strength (Ebf) of yttria films for application in semiconductor manufacturing, a synthetic strategy based on photo-assisted chemical solution deposition was developed to prepare yttria films with aggregates of very small nanocrystallites. Despite containing many elliptical pores, the films exhibited an Ebf exceeding 12.7 MV cm−1, much higher than that predicted according to conventional experimental scaling laws. The combination of nanocrystallite agglomerates and elliptical pores, generally seen as defects, provides a new strategy for increasing the Ebf.
