Ultramicroporous Crosslinked Polyxanthene-Poly(biphenyl piperidinium)-based Anion Exchange Membranes for Water Electrolyzers Operating under Highly Alkaline Conditions

Abstract

Anion exchange membrane water electrolyzers (AEMWEs) suffer from low efficiencies and durability, due to the unavailability of appropriate anion exchange membranes (AEM). Herein, a rigid ladder-like polyxanthene crosslinker was developed for the preparation of ultramicroporous crosslinked polyxanthene-poly(biphenyl piperidinium)-based AEMs. Due to the synergetic effects of ultramicroporous structure and microphase-separation morphology, the crosslinked membranes showed high OH− conductivity (up to 163 mS cm-1 at 80 oC). Furthermore, these AEMs also exhibited moderate water uptake, excellent dimensional stability, and remarkable alkaline stability. The single-cell AEMWE based on QPBP-PX-15% and equipped with non-noble catalysts achieved a current density of 3000 mA cm-2 at 2.03 V (compared to PiperION’s 2.26 V) in 6 M KOH solution at 80 oC, which outperformed many AEMWEs that used platinum-group-metal catalysts. Thus, the crosslinked AEMs developed in this study showed significant potential for applications in AEMWEs fed with concentrated alkaline solutions.
