Issue 10, 2024

Innovations in water desalination: enhancing air gap membrane distillation performance by the incorporation of clay nanoparticles into PVDF matrix membranes

Abstract

This study showcases the remarkable permeate flux rates achieved in water desalination using phase-inversion polyvinylidene difluoride (PVDF) membranes by the incorporation of clay nanoparticles within the polymer matrix, leading to a performance that surpasses that of commercial membranes. These findings hold promising implications for addressing water scarcity issues in various regions around the globe. The study focuses on membrane improvement by incorporating both montmorillonite (MT) and Cloisite 20A (organomontmorillonite, OMT). The permeate flux of the most effective OMT-enhanced membrane (with a 4 wt% loading) surpassed that of the commercial PVDF membrane by 12% and outperformed the pure PVDF membrane by 30% after a 24 hour testing period in air gap membrane distillation (AGMD), with rejection values exceeding 99.8%. Moreover, this membrane exhibited stability over 5 days of continuous testing, proving better performance than commercial PVDF membranes when exposed to a concentrated fouling humic acid solution. This fouling test experienced a 40% reduction in permeate flux compared to the 60% decline observed in the commercial PVDF membrane. These enhancements are attributed to increased surface porosity, higher liquid entry pressure, smaller mean pore size, and a uniform distribution of clay particles within the membrane matrix.

Graphical abstract: Innovations in water desalination: enhancing air gap membrane distillation performance by the incorporation of clay nanoparticles into PVDF matrix membranes

Supplementary files

Article information

Article type
Paper
Submitted
21 Apr 2024
Accepted
23 Jul 2024
First published
24 Jul 2024
This article is Open Access
Creative Commons BY license

Environ. Sci.: Water Res. Technol., 2024,10, 2418-2431

Innovations in water desalination: enhancing air gap membrane distillation performance by the incorporation of clay nanoparticles into PVDF matrix membranes

R. Navarro-Tovar, P. Gorgojo, M. Jobson, P. Martin and M. Perez-Page, Environ. Sci.: Water Res. Technol., 2024, 10, 2418 DOI: 10.1039/D4EW00326H

This article is licensed under a Creative Commons Attribution 3.0 Unported Licence. You can use material from this article in other publications without requesting further permissions from the RSC, provided that the correct acknowledgement is given.

Read more about how to correctly acknowledge RSC content.
