RAFT dispersion polymerization in non-polar solvents: facile production of block copolymer spheres, worms and vesicles in n-alkanes

Abstract

Well-defined poly(lauryl methacrylate-benzyl methacrylate) (PLMA-PBzMA) diblock copolymer nanoparticles are prepared in n-heptane at 90 °C via reversible addition–fragmentation chain transfer (RAFT) polymerization. Under these conditions, the PLMA macromolecular chain transfer agent (macro-CTA) is soluble in n-heptane, whereas the growing PBzMA block quickly becomes insoluble. Thus this dispersion polymerization formulation leads to polymerization-induced self-assembly (PISA). Using a relatively long PLMA macro-CTA with a mean degree of polymerization (DP) of 37 or higher leads to the formation of well-defined spherical nanoparticles of 41 to 139 nm diameter, depending on the DP targeted for the PBzMA block. In contrast, TEM studies confirm that using a relatively short PLMA macro-CTA (DP = 17) enables both worm-like and vesicular morphologies to be produced, in addition to the spherical phase. A detailed phase diagram has been elucidated for this more asymmetric diblock copolymer formulation, which ensures that each pure phase can be targeted reproducibly. ¹H NMR spectroscopy confirmed that high BzMA monomer conversions (>97%) were achieved within 5 h, while GPC studies indicated that reasonably good blocking efficiencies and relatively low diblock copolymer polydispersities (M_w/M_n < 1.30) were obtained in most cases. Compared to prior literature reports, this all-methacrylic PISA formulation is particularly novel because: (i) it is the first time that higher order morphologies (e.g. worms and vesicles) have been accessed in non-polar solvents and (ii) such diblock copolymer nano-objects are expected to have potential boundary lubrication applications for engine oils.
